Code CR3500 Quick Start Manual

Reading Tips
Quick Tips
1. Press either trigger button to turn the reader
on, or to scan a bar code.
2. Press the Soft Key, under 'Options' to:
manually enter data, view stored data,
connect to a Bluetooth device, send all stored
data to a PC, and change reader settings.
3. Use the arrow buttons to navigate through
lists, data and more.
4. Use the Enter button to select an item.
Visit www.codecorp.com to download the CR3500
User Manual for a complete reference guide of CR3500
functions.
4
The reader is too far from a
bar code (more than 12"
from the bar code reader).
The reader is too close to a
bar code (less than 1"
from the bar code reader).
The optimal distance to read
most bar codes is 3-4" away
from the bar code reader.
CR3500's unique targeting function uses two converging
targeting LEDs to guide the user to optimal reading range.
© 2012. Code Corporation. All Rights Reserved.
Code Reader™ 3500 (CR3500) - Wireless
Included with your Wireless CR3500
Depending on the reader configuration ordered, you will have received one of the
following with your CR3500:
Battery Cartridge Battery Handle
Installing a Battery Cartridge
1. To install a battery, place the plastic tab on the bottom
of the battery cartridge into the slot on the reader.
Slide the locking mechanism up, and press the battery
into place. Slide the locking mechanism down to
secure the battery.
2. To detach a battery, slide the locking mechanism on
the reader up and pull the battery cartridge up and
away from the slot on the reader.
Note: Battery ships with approximately 50% battery life. Fully charge battery before use.
Approximate charge time is 4 hours when battery depleted.
C004419_03_CR3500_Quickstart_Wireless
Quickstart Guide
