Code Reader CR3500 Quick Start Manual

Reading Tips
The reader is too far from a
bar code (more than 12"
from the bar code reader).
The reader is too close to a
bar code (less than 1"
from the bar code reader).
The optimal distance to read
most bar codes is 3-4" away
from the bar code reader.
Quick Tips
1. Press either trigger button to turn the reader on, or to scan a bar code.
2. Press the Soft Key, under 'Options' to: manually enter data, view stored data, connect to a
Bluetooth device, send all stored data to a PC, and change reader settings.
3. Use the arrow buttons to navigate through lists, data and more.
4. Use the Enter button to select an item.
Visit www.codecorp.com to download the CR3500 User Manual for a complete reference guide of
CR3500 functions.
4
CR3500's unique
targeting function uses
two converging targeting
LEDs to guide the user to
optimal reading range.
© 2012. Code Corporation. All Rights Reserved.
Code Reader™ 3500 (CR3500) - Cabled
Included with your Cabled CR3500
Depending on the reader configuration ordered, you will have received some of the
following with your CR3500:
Blank Battery Cartridge H2 Handle
Installing a Blank Battery Cartridge
1. To install a blank battery cartridge, place the plastic
tab on the bottom of the battery cartridge into the
slot on the reader. Slide the locking mechanism up,
and press the battery into place. Slide the locking
mechanism down to secure the battery.
2. To detach a battery, slide the locking mechanism on
the reader up and pull the battery cartridge up and
away from the slot on the reader.
C004418_03_CR3500_Cabled_Quickstart
Quickstart Guide
USB Cable RS232 Cable
