metrofires ECO Tiny Ped Installation & Owner's Operation Manual

Wood fire clean air freestanding models

Hide thumbs Also See for ECO Tiny Ped:

Installation manual (17 pages)

Table of Contents

Quick Links

Need help?

Do you have a question about the ECO Tiny Ped and is the answer not in the manual?

Questions and answers

Summary of Contents for metrofires ECO Tiny Ped

Page 1: Table Of Contents
Wood Fire Installation & Owner’s Operation Manual Clean Air Freestanding Models • ECO Tiny Ped • R1 • Wee Rad • Xtreme Rad • ECO Euro Rad • ECO Tiny Rad • R2 • Wee Rad Base • Xtreme Rad Base •...
Page 2: Installation Important Information
WARNING! CAUTION! Important Information Important Information • WE HIGHLY RECOMMEND YOU READ THIS ENTIRE • Mixing of appliance or flue-system components MANUAL AS INCORRECT OPERATION, MISUSE AND/OR from different sources or modifying the dimensional LACK OF MAINTENANCE WILL VOID THE WARRANTY specification or components may result in hazardous conditions.
Page 3 Refer to Diagram 2. Note: The ECO Tiny Ped model utilises a slightly different pedestal to that detailed in Diagram 1. The rear panel on the pedestal must be turned around with the return fold facing back the opposite way. This creates the mounting plate.
Page 4: Direct Vent Option
Direct vent option The ECO Euro Ped and ECO Euro Rad models have the option Installing the Direct Vent Option to be installed as “Direct Vent” appliances, thereby drawing Remove the rear heatshield from the Metro wood fire by all primary and secondary combustion air from outside the unscrewing the four self-tapping screws illustrated in Diagram home.
Page 5: Floor Protector Installation
Metro to the floor. Metro Pedestal Fires These models (excluding the ECO Tiny Ped) are supplied with a “pedestal mounting plate”. Refer to Diagram 1 on page 3. Place the mounting plate on the floor protector with the two slots at the rear.
Page 6: Clearances And Specifications
(Minimum clearances shown are in mm, with a Pioneer double flue shield fitted) Minimum installation clearances with a Pioneer double flueshield fitted (mm) Wetback Dimensions Clean Air Models Width Depth Height ECO Tiny Ped ECO Tiny Rad 1165 1370 1118 1449 1203...
Page 7: Wetback And Flue Installation
A copy of the installation manual can be downloaded from All Metro’s have been tested with a Pioneer double flue mounted www.metrofires.co.nz, or a copy can be obtained from your shield. For the Metro to be installed Metro retailer. Any alternative flue system must comply with...
Page 8: Operation Important Information
WARNING! CAUTION! Important Information Important Information • WE HIGHLY RECOMMEND YOU READ THIS ENTIRE • This appliance should be maintained & operated at all MANUAL AS INCORRECT OPERATION, MISUSE AND/OR times in accordance with this instruction manual LACK OF MAINTENANCE WILL VOID THE WARRANTY •...
Page 9: Where To Install A Metro In Your Home
Metro offer a 2kW wetback suitable for hours a day over the colder months, electricity savings will be the ECO Tiny Rad and ECO Tiny Ped. The Ambie One cannot be considerably less. fitted with a wetback in a clean air zone, but can be fitted with a wetback if installed on a 2HA+ rural property.
Page 10: Getting To Know Your Metro
Getting to know your Metro wood fire Operating your Metro wood fire is simple and you will quickly learn how to get the best from it. First take a minute to familiarise yourself with your new Metro. • Raise the door handle anti-clockwise until the latch releases, and then slowly pull the door open.
Page 11: Cleaning And Maintenance
Cleaning and maintenance for your Metro wood fire The Metro radiant fires are painted wood fires and coated To remove the excess ash your Metro should not be operating. with “Pioneer Metallic Black” high temperature paint and will • Open the door, and using a hearth shovel or similar, empty require periodic repainting to keep them looking their best.
Page 12: Troubleshooting
Troubleshooting your Metro wood fire If your Metro did not smoke, but its starting too and If your Metro is installed correctly, your fuel is dry and you operate your fire correctly, you will find it to be a pleasure to is getting worse: use.
Page 13: Metro Warranty
Warranty details for your Metro wood fire Metro wood fires are manufactured in New Zealand, using • It is critical that the fire not be operated with over worn, faulty the highest quality of materials, workmanship and the latest or missing door seals. Door seals will harden over time and manufacturing techniques, which is why we offer a full 10 year become over-worn (3-4 year’s) this will cause air to leak into firebox warranty and 1 year parts warranty for peace of mind.
Page 14: Pioneer Wood Fire Accessories
See your Metro retailer to obtain a copy, or visit www.metrofires.co.nz metrofires.co.nz Visit the Metro website: www.metrofires.co.nz to view Metro’s ‘video demos’ showing the latest in wood fire technology energy saving options. You can view the entire Metro product range,...
Page 15 Type of promet required / Type of steel baffle(s) required Water heating options Clean air models ECO Tiny 500-1550 ECO Tiny Complete 500-2050 ECO 2kW Booster 450-0050 • ECO Tiny Ped • ECO Tiny Rad Wee/R1 Set 500-2005 Wee/R1 Complete 500-2505 • R1 No wetback can be fi tted...
