Wood Fire Installation & Owner's Operation Manual
ECO Mega Smart Built-In
Installation Important information ..........2
Preparing the wall/opening cavity .........3
Installing your Metro ................................4
Floor protector requirements ...................5
Flue and wetback Installation.................6
Operation Important information ...........7
Getting to know your Metro ....................8
Operating your Metro ..............................8
Cleaning and maintenance .............9-10
Replacement parts ...............................10
Troubleshooting .....................................11
Metro warranty.......................................12
PO Box 11, Inglewood 4347, New Zealand
Ph (06) 756 6520 • Fax (06) 756 6540
info@metrofires.co.nz • www.metrofires.co.nz
Advertisement
Table of Contents
Related Manuals for metrofires ECO Mega Smart Built-In
Summary of Contents for metrofires ECO Mega Smart Built-In
-
Page 1: Table Of Contents
Wood Fire Installation & Owner’s Operation Manual ECO Mega Smart Built-In Installation Important information ..2 Getting to know your Metro ....8 Preparing the wall/opening cavity ..3 Operating your Metro ......8 Installing your Metro ........4 Cleaning and maintenance .....9-10 Floor protector requirements ....5 Replacement parts .......10... -
