Wood Fire Installation & Owner's Operation Manual
B
D
F
G
C
J
Mega Smart Built-In
Floor protector requirements ..................Page 8
Fitting the fascia ...................................Page 10
K
Getting to know your Metro ...................Page 12
Operating your Metro ...........................Page 12
Cleaning and maintenance ..................Page 13
Replacement parts ..............................Page 14
Troubleshooting ...................................Page 15
Metro warranty .....................................Page 16
19 Oropuriri Road // New Plymouth 4312
info@metrofires.co.nz // www.metrofires.co.nz

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mega Smart Built-In and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for metrofires Mega Smart Built-In

Summary of Contents for metrofires Mega Smart Built-In

  • Page 1: Table Of Contents

    Where to install a Metro in your home ...Page 12 Preparing the wall/opening cavity ...Page 3 Getting to know your Metro ....Page 12 Installing the Mega Smart Built-In ...Page 5 Operating your Metro ......Page 12 Installing the ECO Built-In flue kit ...Page 6 Cleaning and maintenance ....Page 13...

  • Page 2: Installation Important Information

    Unpacking and familiarisation Supplied with the Metro Mega Smart Built-In: The function of the Metro Mega Smart Built-In is to enable the fire to be installed into a timber framed wall replacing a masonry chimney at a fraction • 1 x 200mm/250mm diameter liner spigot of the cost.

  • Page 3: Preparing The Wall/Opening Cavity

    Stage 1 - Construction and preparation of the wall opening/cavity WARNING! Important Information DIAGRAM 1 • Access is required to fit the flue spigot adaptor to the Mega Smart firebox and for installation of the ECO Built-In flue kit. Pioneer Manufacturing recommend lining the walls of the enclosure after the Mega Smart and flue kit have been installed.
  • Page 4 Venting through the top of the enclosure using the ‘ECO Option Kit’ with As the Mega Smart Built-In is built into an enclosure, the enclosure must the Metro ECO Built-In flue kit. If you choose to vent the enclosure with be vented using one of the three options detailed below.

  • Page 5: Installing The Mega Smart Built-In

    VZCC forward so the front edge of the base panel ends up flush with the front face of the bricks once constructed. If you are fitting the water heater to the Mega Smart built-in, please refer to the installation instructions included with the water heater.

  • Page 6: Installing The Eco Built-In Flue Kit

    Metro ECO Built-in flue kit. Only the Metro ECO Built-In Flue Kit can be used for installation with the Metro (D) 1 x 480mm long stainless steel flue Mega Smart Built-In wood fire. pipe extension with flashing cone (E) 3 x 1200mm x 150mm diameter •...
  • Page 7 Stage 3 - Installation of the Metro ECO Built-In flue kit Fit the 480mm long flue pipe extension/flashing cone (D), with the flashing cone at the bottom, fit its short flue section inside the top of the already installed 150mm diameter flue pipe. Ensure the three brackets extended below the flashing cone fit ‘outside’...

  • Page 8: Floor Protector Requirements

    All installations of the Mega Smart Built-In onto a concrete or non combustible floor structure only require an ash hearth floor protector If the Mega Smart Built-In is to have a raised floor protector, the base that complies with AS/NZS 2918:2001 and this installation manual. (See on which the Mega Smart Built-In firebox will be installed needs to be Diagrams 9 &...
  • Page 9 Stage 4 – Construction and installation of the floor protector (hearth) ø250mm ø250mm Stud wall Stud wall ø200mm ø200mm Wall lining Wall lining ø150mm ø150mm DIAGRAM 7 DIAGRAM 8 Spigot adapter Mega Smart firebox Spigot adapter Mega Smart firebox Insulated Insulated floor protector floor protector VZCC...

  • Page 10: Fitting The Fascia

    500mm follows; above the top of the Mega Smart Built-In fascia to the underside of the With the door in a 45 degrees open position, allow the lower hinge mantel.

  • Page 11: Operation Important Information

    WARNING! CAUTION! Important Information Important Information WE HIGHLY RECOMMEND YOU READ THIS ENTIRE • This appliance should be maintained & operated at all times in • accordance with this instruction manual MANUAL AS INCORRECT OPERATION, MISUSE AND/OR LACK OF MAINTENANCE WILL VOID THE WARRANTY •...

  • Page 12: Where To Install A Metro In Your Home

    There is a single air control making your Metro fire easy to adjust. This control moves from left to right, which is ‘low to high’. Mega Smart Built-In air control Operating your Metro wood fire If your Metro has only been installed within the past few days, the fire well, open the door and add 2-3 small logs at a time until you have a well- cement seal at the base of the flue will not be fully cured.

  • Page 13: Cleaning And Maintenance

    • If the ash is not disposed of immediately, be careful where you store it, The Metro Mega Smart Built-In fascia is coated with vitreous enamel. as the ash can retain heat for many days and become a fire hazard.

  • Page 14: Replacement Parts

    Cleaning and maintenance for your Metro wood fire Flue systems Note: The Mega Smart Built-In features a two piece top baffle. • Close the door and slide the air control to the left. Should be checked annually, particularly the bottom end of the lower flue section at its rear lock formed joint.

  • Page 15: Troubleshooting

    Troubleshooting your Metro wood fire If your Metro is installed correctly, your fuel is dry and you operate your Air turbulence and/or negative air pressure influences around the flue fire correctly, you will find it to be a pleasure to use. Metro’s many years of termination can be caused by too close or overhanging trees or natural/ experience within the wood heating industry has shown that dissatisfaction artificial ridges etc.

  • Page 16: Metro Warranty

    Warranty details for your Metro wood fire Metro wood fires are manufactured in New Zealand, using the highest CAUTION! quality of materials, workmanship and the latest manufacturing techniques, Important Information which is why we offer a full 10 year firebox warranty and a 1 year parts warranty for your peace of mind.
