- Page 1 Recycling Manual Caravan Generator June 2003 English Dometic AB...
- Page 2 This guide takes you through the dismantling of Dometic generators for caravans in a simple, step-by-step process. By following these steps it will be easier to separate reusable materials and minimise the time required for dismantling.
- Page 3 2. separate other components for recycling The remaining part of the unit (mainly the engine) should be fragmented together with vehicle. Exploded view of caravan generator TEC29 Operations in order 1. Dismount door (Part A) and cover (part B) from generator. Separate noise insulation from door and cover.
- Page 4 2. Turn unit upside down and loosen inverter control (Part C), including internal control panel and the battery on back side. 3. Dismount cover (Part D) and separate interior insulation from cover. 4. Dismount fan cover (Part E). 5. Dismount ventilator (Part F). 6.
- Page 5 7. Dismount rotor (Part H) by using a withdrawing tool. 8. Dismount stator (Part I). 9. Dismount muffler (Part J). 10. Dismount alternator housing (Part K). 11. Dismount start motor (Part L). Page 5...
- Page 6 12. Dismount step motor kit (Part M). 13. Dismount the control panel (Part N) inside the caravan and the connection cables. The remaining part of the generator should be fragmented together with the vehicle. Page 6...
- Page 7 Table Pos. Component / Part Tool to dismount Recyclable Waste Door Metal (steel) House Ph. screwdriver Metal (steel) Inverter (with terminal board Spanner 8mm, cutting Electric waste and battery) pliers Cover Ph. screwdriver Metal (steel) Cover Ph. screwdriver Metal (steel) Ventilator Key for socket screw 4 Plastic (PA)
