- Page 1 ENERGY & LIGHTING TRAVELLER T2500 H/HG-LP, T4000 H/HG-LP, T5500 H/HG-LP Generator Installation and Operating Manual ..1 Generatore Istruzioni di montaggio e d’uso ..10 Generator Montage- und Bedienungsanleitung . . .19...
- Page 2 START FIG. 1 FIG. 5 230 V 230 V 12 V 1 7 1 8 FIG. 2 FIG. 6 FIG. 3 FIG. 7 FIG. 4 FIG. 8...
- Page 3 No part of this publication may be reproduced, copied or transmitted in any form or by any means without prior written permission from DOMETIC ITALY srl. Figures, descriptions, reference and technical data in this manual are given as mere example and are not binding.
-
Page 4: Installation
The generator shall be installed onto the vehicle (caravan, motorhome or special vehicle) by authorised personnel Mod. 5500 .......... Kg 140 only, namely by skilled technicians or workshops, authorised directly by DOMETIC ITALY srl If the installation is carried out by non-authorized technicians... -
Page 5: Electrical Connections
2.3 ELECTRICAL CONNECTIONS or workshops, Dometic Italy disclaims any responsibility For the 230V use a standard cable with cross-section for the safety and efficient running of the generatore according to table 1 below. Pass it inside the casing via the accordind to the M.D. -
Page 6: General Operation
cannot infiltrate. DANGER Use LOCTITE 577 to make all connections, so as to prevent fuel leakages. To connect the fuel tank to the generator, use a 6x13mm rubber-coated tube, of the same type used for the genset • The unit shall be used only and exclusively with the door and suitable for unleaded petrol. -
Page 7: Troubleshooting
INSTRUCTIONS FOR USE IMPROPER USE DANGER STARTING THE GENERATOR Normally the vehicle's 12V battery is used to start the The generator is to be installed by qualified technicians only, genset. according to the manufacturer’s instructions. First press the red button (pos. 27 fig. 5) on the control panel The generator is to be used only and exclusively for producing into the “I”... -
Page 8: Maintenance Operations Which Do Not Require Qualified Technicians
The generator tends to stall. NATURE AND FREQUENCY OF CHECKS Causes and Solutions: No more fuel left in the tank: refill. ORDINARY MAINTENANCE INTERVAL Every First Every Every Low oil level. Every month 3 months 6 months year carry out at the intervals or after the running hours given in the table, depending on which Check and top up. -
Page 9: Oil Change
5.3.1 OIL CHANGE 5.3.2 AIR FILTER MAINTENANCE IMPORTANT 15W 50 Hot climates A dirty air filter reduces the air flow to the carburettor. To MULTIGRADE SG / SF 10W 30 keep the carburettor working properly, check it often. Check Cold climates more frequently if the engine is used in dusty areas. -
Page 10: Regulating The Voltage
IMPORTANT When mounting a new spark plug, tighten it a half-turn after it has compressed the washer. When re-using the same spark plug, tighten it 1/8-1/4 turn after the washer compression. CAUTION The spark plug should be tightened carefully. A loose spark plug can get very hot and damage the engine. -
Page 11: Technical Data
TECHNICAL DATA TECHNICAL SPECIFICATIONS ENGINE 2500H 4000H 5500H Type Singlecylinder, fourstroke, overhead valves Honda model GX 160 GX 270 GX 390 Displacement Stroke x bore 68x45 77x58 88x64 Consumption gkW/h Fuel Leadfree petrol Starter system Electronic Spark plug Engineoil sump capacity litre Frequency r e g o l a t o r Automatic with centrifugal masses...
