NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Identifier
Assembly Instruction
Warranty
Model
MP-2106
Retain This
Manual for
Reference
09-10-07
OWNER'S
MANUAL
MARCY PLATINUM
MP-2106 HOME GYM
Escalade International Limited
Pleasant Road, Penllergaer, Swansea. SA4 9GE
Tel: 00 44 1792 222 550 Fax 00 44 1792 895 781
www.escaladesports.co.uk
info@escaladesports.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MP-2106 and is the answer not in the manual?

Questions and answers

Summary of Contents for Marcy MP-2106

  • Page 1 NOTE: Please read all instructions carefully before using this product MARCY PLATINUM Table of Contents MP-2106 HOME GYM Safety Notice Hardware Identifier Assembly Instruction Parts List Warranty Ordering Parts Model MP-2106 Retain This Manual for Reference 09-10-07 OWNER'S MANUAL Escalade International Limited Pleasant Road, Penllergaer, Swansea.
  • Page 2 ORDERING PARTS..................BEFORE YOU BEGIN Thank you for selecting the MARCY PLATINUM Home Gym MP-2106. For your safety and benefit, read this manual carefully before using the machine. As the distributor, we are committed to provide you complete customer satisfaction.
  • Page 3: Important Safety Precautions

    IMPORTANT SAFETY PRECAUTIONS This Gym is built for optimum safety. However, certain precautions apply whenever you operate a piece of exercise equipment. Be sure to read the entire manual before you assemble or use your Gym. In particular, note the following safety precautions: 1.
  • Page 4 WARNING LABEL...
  • Page 5 HARDWARE PACK...
  • Page 6 HARDWARE PACK...
  • Page 7 HARDWARE PACK...
  • Page 8: Assembly Instruction

    ASSEMBLY INSTRUCTION Tools Required Assembling the Machine: Two Adjustable Wrenches and Allen Wrenches NOTE: It is strongly recommended this machine be assembled by two or more people to avoid possible injury. STEP 1 (See Diagram 1) A.) Insert two Guide Rods (#16) into the holes on the Rear Stabilizer (#15). Secure each Guide Rod with one M10 x ¾”...
  • Page 9 DIAGRAM 1...
  • Page 10 STEP 2 (See Diagram 2) A.) Attach the Upper Frame (#1) onto the two Guide Rods (#16). Secure it with two M10 x ¾” Allen Bolts (#78) and ∅ ¾” Washers (#92). DO NOT tighten the Bolts yet. B.) Place the Upper Frame (#1) onto the Vertical Frame (#4). Secure it with two M10 x 2 ¾”...
  • Page 11 STEP 3 (See Diagram 3) A.) Attach the Front Press Base (#2) to the Upper Frame (#1). Secure it with one 6 ¾” Front Press Base Axle (#29), two Ø 1 ¼” Washers (#59), and two M10 Aircraft Nuts (#91). B.) Attach the Front Press (#3) to the Front Press Base (#2).
  • Page 12 DIAGRAM 3...
  • Page 13 STEP 4 (See Diagram 4) A.) Attach the Seat (#32) to the Seat Post (#6). Secure it with two M8 x 1 5/8” Allen Bolts (#86) and Ø 5/8” Washers (#88). B.) Insert the Seat Post into the opening on the Seat Support Frame (#7). Thread the Lock Knob (#40) into the hole on the Seat Support Frame to lock the Seat at selected height.
  • Page 14 STEP 5 (See Diagram 5) A.) Slide the Right Butterfly (#10) onto the right axle on the Butterfly Base (#13). B.) Insert the Butterfly Handle (#9) into the pivot on the Right Butterfly. Secure it with one M10 x ¾” Allen Bolt (#78) and ∅ 1 ¼” Washer (#59) from the bottom. C.) Repeat Procedures A and B above to install the other side.
  • Page 15 CABLE LOOP DIAGRAM...
  • Page 16 STEP 6 (See Diagram 6 & Upper Cable Loop Diagram) A.) Attach the 163” Upper Cable (#33) to the opening on the front of Upper Frame (#1). Make sure the ball stopper is underneath the Frame. Attach a Pulley (#47) to the Cable.
  • Page 17 DIAGRAM 6...
  • Page 18 Upper Cable Loop Diagram...
  • Page 19 STEP 7 (See Diagram 7 & Lower Cable Loop Diagram) A.) Attach the 164” Lower Cable (#35) to the opening on the Leg Developer (#8). Attach a Pulley (#47) to the opening. Secure it with one M10 x 2 ½” Allen Bolt (#84), two ∅ 7/8”...
  • Page 21 Lower Cable Loop Diagram...
  • Page 22 STEP 8 (See Diagram 8 & Butterfly Cable Loop Diagram) A.) Clip one end of the 98” Butterfly Cable (#34) to the open slot on the Right Butterfly (#10). B.) Draw the Cable to the open bracket on the right side of the Vertical Frame (#4). Attach a Small Pulley (#73) to the bracket C.) Secure it with one M10 x 1 ¾”...
  • Page 24 Butterfly Cable Loop Diagram...
  • Page 25 STEP 9 (See Diagram 9) A.) Connect the Lat Bar (#24) to the Upper Cable (#33) with two Hooks (#37) and one Chain (#36). B.) Connect the Abdominal Strap (#70) to the Lower Cable (#35) with a Hook. C.) Connect the Shiver Bar (#19) to the Lower Cable with two Hooks and a Chain. Replace Shiver Bar with Single Handle (#68) or Ankle Strap (#69) for various exercises.
  • Page 26 Step 10 (See Diagram 10) A.) Attach the two Weight Stack Covers (#74) to the Upper Frame (#1) and Rear Stabilizer (#15). B.) Secure them with four M10 x ¾” Allen Bolts (#78) and four Ø ¾” Washers (#92). DIAGRAM 10...
  • Page 27: Weight Resistance Chart

    WEIGHT RESISTANCE CHART WEIGHT PLATE Station Low Pulley Lat Pull Butterfly Front Press AB Crunch Leg Developer WEIGHT PLATE Station Low Pulley Lat Pull Butterfly Front Press AB Crunch Leg Developer *All weights are in KGS *Numbers are approximate. Actual weight may vary. *Value for butterfly is for each arm.
  • Page 28: Parts List

    PARTS LIST KEY NO. DESCRIPTION Q’ty Upper Frame Ø 1 ¼” Front Press Bushing Front Press Base Ø 7/8” Leg Developer Bushing ∅ 1” Bushing Front Press Vertical Frame Ø 1” Spacer Backrest Support Frame Rubber Bumper Seat Post Ø 1 ½” Spacer Seat Support Frame Ø...
  • Page 29: Limited Warranty

    LIMITED WARRANTY Escalade warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of two years on the frame and one year on all other parts and components from the date of purchase. This warranty extends only to the original purchaser.
