Marcy PLATINUM MP-3500 Owner's Manual

Home gym
Hide thumbs
Table of Contents

Advertisement

Quick Links

NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Identifier
Warranty
Model
MP-3500
Retain This
Manual for
Reference
08-25-09
OWNER'S
MANUAL
MARCY PLATINUM
MP-3500 HOME GYM
Escalade International Limited
Pleasant Road, Penllergaer Swansea. SA4 9GE
Tel: 00 44 1792 222550 Fax: 00 44 1792 895781
.escaladesports.co.
info@escaladesports.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLATINUM MP-3500 and is the answer not in the manual?

Questions and answers

Related Manuals for Marcy PLATINUM MP-3500

Summary of Contents for Marcy PLATINUM MP-3500

  • Page 1 NOTE: Please read all instructions carefully before using this product MARCY PLATINUM Table of Contents MP-3500 HOME GYM Safety Notice Hardware Identifier Assembly Instruction Parts List Warranty Ordering Parts Model MP-3500 Retain This Manual for Reference 08-25-09 OWNER'S MANUAL Escalade International Limited Pleasant Road, Penllergaer Swansea.
  • Page 2 ORDERING PARTS..................BEFORE YOU BEGIN Thank you for selecting the MARCY PLATINUM Home Gym MP-3500. For your safety and benefit, read this manual carefully before using the machine. As the distributor, we are committed to provide you complete customer satisfaction.
  • Page 3 IMPORTANT SAFETY PRECAUTIONS This Gym is built for optimum safety. However, certain precautions apply whenever you operate a piece of exercise equipment. Be sure to read the entire manual before you assemble or use your Gym. In particular, note the following safety precautions: 1.
  • Page 4 WARNING LABEL PLACEMENT...

  • Page 5: Hardware Pack

    HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.
  • Page 6 HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size. （Qty 74）...
  • Page 7 HARDWARE PACK...

  • Page 8: Assembly Instruction

    ASSEMBLY INSTRUCTION Tools Required for Assembling the Machine: Two Adjustable Wrenches and Allen Wrenches NOTE: It is strongly recommended that two or more people assemble this machine to avoid possible injury. STEP 1 (See Diagram 1) A.) Insert two Guide Rods (#17) into the holes on Rear Stabilizer (#16). Secure each Guide Rod with one M10 x ¾”...
  • Page 9 DIAGRAM 1...
  • Page 10 STEP 2 (See Diagram 2) A.) Attach the Upper Frame (#1) onto the two Guide Rods (#17). Secure it with two M10 x ¾” Allen Bolts (#103) and ∅ ¾” Washers (#111). DO NOT tighten the Bolts yet. B.) Place the Upper Frame onto the Vertical Frame (#4). Secure it with two M10 x 2 5/8” Carriage Bolts (#106), one 4 ¾”...
  • Page 11 STEP 3 (See Diagram 3) A.) Attach the Front Press Base (#2) to the Upper Frame (#1). Secure it with one 6 ¾” Front Press Base Axle (#29), two Ø 1 ¼” Washers (#70), and two M10 Aircraft Nuts (#109). B.) Attach the Front Press (#3) to the Front Press Base.
  • Page 12 DIAGRAM 3...
  • Page 13 STEP 4 (See Diagram 4) A.) Attach the Seat Pad (#88) to the Seat Post (#6). Secure it with two M8 x 1 5/8” Allen Bolts (#113) and Ø 5/8” Washers (#112). B.) Insert the Seat Post into the opening on the Seat Support Frame (#7). Thread the 3 3/8”...
  • Page 14 DIAGRAM 4...
  • Page 15 STEP 5 (See Diagram 5) A.) Slide the Right Butterfly (#10) onto the right axle on the Butterfly Base (#13). B.) Insert the Butterfly Handle (#9) into the pivot on the Right Butterfly. Secure it with one M10 x ¾” Allen Bolt (#103) and ∅ 1 ¼” Washer (#70) from the bottom. C.) Repeat Procedures A and B above to install the other side.
  • Page 16 STEP 6 (See Diagram 6 & Upper Cable Loop Diagram) A.) Attach the 167” Upper Cable (#42) to the opening on the front of Upper Frame (#1). Make sure the ball stopper is underneath the Frame. Attach a Pulley (#44) to the Cable. B.) Secure the Pulley to the opening with one M10 x 3 3/8”...
  • Page 17 DIAGRAM 6...
  • Page 18 Upper Cable Loop Diagram...
  • Page 19 STEP 7 (See Diagram 7 & Lower Cable Loop Diagram) A.) Attach the 215” Lower Cable (#40) to the opening on the Leg Developer (#8). Attach a Pulley (#44) to the opening. Secure it with one M10 x 2 ½” Allen Bolt (#98), two ∅ 7/8”...
  • Page 20 DIAGRAM 7...
  • Page 21 Lower Cable Loop Diagram...
  • Page 22 STEP 8 (See Diagram 8 & Butterfly Cable Loop Diagram) A.) Clip one end of the 83” Butterfly Cable (#41) to the open slot on the Right Butterfly (#10). B.) Draw the Cable to the open bracket on the right side of the Vertical Frame (#4). Attach a Small Pulley (#45) to the bracket C.) Secure it with one M10 x 1 ¾”...
  • Page 24 Butterfly Cable Loop Diagram...
  • Page 25 STEP 9 (See Diagram 9) A.) Connect the Lat Bar (#24) to the 167” Upper Cable (#42) with two Hooks (#90) and one Short Chain (#75). B.) Attach the Abdominal Strap (#85) to the U-shaped Cable Connector (#48) on the 215” Lower Cable (#40) with a Hook (#90).
  • Page 26 STEP 10 (See Diagram 10) A.) Attach one end of 75” Hip-Thigh Cable (#39) to the bracket on the Rotating Cam Plate (#32). Secure it with one M10 x 1” Allen Bolt (#102), two Ø ¾” Washers (#111), and one M10 Aircraft Nut (#109).
  • Page 27 Hip-Thigh Cable Loop Diagram...
  • Page 28 STEP 11 (See Diagram 11) A.) Attach the two Weight Stack Covers (#46) To Upper Frame (#1) and Rear Base Frame (#15) from each side. B.) Secure the Weight Stack Covers to the Upper Frame and Rear Base Frame with four M10 x ¾”...

  • Page 29: Weight Resistance Chart

    WEIGHT RESISTANCE CHART WEIGHT PLATE Station Low Pulley 13.5 22.5 31.5 40.5 Lat Pull 13.5 22.5 31.5 40.5 49.5 Butterfly 6.75 11.25 13.5 15.75 20.25 12.5 Front Press 15.75 22.5 29.25 42.75 49.5 56.25 AB Crunch 13.5 22.5 31.5 40.5 13.5 22.5 31.5...
  • Page 30 PARTS LIST KEY NO. DESCRIPTION Q’ty Upper Frame 5 3/8” Grip Front Press Base Ø 1” End Cap Front Press 2” x 2” End Cap Vertical Frame 1” x 2” End Cap Backrest Support Frame 1” x 2 ¾” End Cap Seat Post 2”...

  • Page 31: Limited Warranty

    LIMITED WARRANTY Escalade warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of two years on the frame and one year on all other parts and components from the date of purchase. This warranty extends only to the original purchaser.
