NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Pack
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
MCB-5702
Retain This
Manual for
Reference
08-09-07
OWNER'S
MANUAL
MARCY CLASSIC
Deluxe Mid-Size Bench
MCB-5702
Escalade International Limited
Pleasant Road, Penllergaer, Swansea. SA4 9GE
Tel: +44 (0) 1792 222550 Fax: +44 (0) 1792 895781
www.escaladesports.co.uk
info@escaladesports.co.uk
Advertisement
Table of Contents
Related Manuals for Marcy CLASSIC MCB-5702
Summary of Contents for Marcy CLASSIC MCB-5702
- Page 1 NOTE: Please read all instructions carefully before using this product Table of Contents MARCY CLASSIC Safety Notice Deluxe Mid-Size Bench Hardware Pack MCB-5702 Assembly Instruction Parts List Warranty Ordering Parts Model MCB-5702 Retain This Manual for Reference 08-09-07 OWNER'S Escalade International Limited MANUAL Pleasant Road, Penllergaer, Swansea.
-
Page 2: Table Of Contents
ORDERING PARTS..................BEFORE YOU BEGIN Thank you for selecting the MARCY CLASSIC DELUXE MID-SIZE BENCH MCB-5702 by IMPEX FITNESS PRODUCTS. For your safety and benefit, read this manual carefully before using the machine. As the distributor, we are committed to provide you complete customer satisfaction. -
Page 3: Important Safety Precautions
PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. MARCY ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT. SAVE THESE INSTRUCTIONS. -
Page 4: Hardware Pack
WARNING LABEL HARDWARE PACK... - Page 5 NOTE: The following parts are not drawn to scale. Please use your own ruler or scale to measure the size.
-
Page 6: Hardware Pack
HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler or scale to measure the size. -
Page 7: Assembly Instructions
ASSEMBLY INSTRUCTION Tools Required Assembling the Machine: Two Adjustable Wrenches and Allen Wrenches. NOTE: It is strongly recommended two or more people assembling this machine to avoid possible injury. STEP 1 (See Diagram 1) A.) Connect the two Upright Beams (#1) by a Cross Brace (#4) in the mid-span. Align the holes and secure each end of Cross Brace to the Upright Beam with two M10 x 4 ¾”... - Page 8 STEP 2 (See Diagram 2) A.) Attach the Main Seat Support (#3) to the Front Post (#9). Secure it with two M10 x 2 3/8” Carriage Bolts (#35), one Small Bent Bracket (#15), two Ø ¾” Washers (#2), and two M10 Aircraft Nuts (#13) vertically. Secure it with one M10 x 4” Carriage Bolt (#34), ∅...
-
Page 9: Main Seat Support
STEP 3 (See Diagram 3) A.) Attach the Seat Bracket (#42) to the pivot on the Main Seat Support (#3). Attach the Backrest Incline Support (#10) in between the two side-holes on the Backrest Supports (#12). Align the Backrest Supports (#12) to the Seat Bracket. Secure them together with one M12 x 6 ¾”... -
Page 10: Ø 5/8" Washer
STEP 4 (See Diagram 4) A.) Insert the Leg Developer Holder (#45) into the opening on the Front Post (#9). Thread a Lock Knob (#26) into the hole on Front Post to hold the Leg Developer Holder in position. B.) Attach the Leg Developer (#8) to the Leg Developer Holder (#9). Secure it with an Axle (#23), two M10 x 5/8”... -
Page 12: Parts List
PARTS LIST KEY NO. DESCRIPTION Q’ty Upright Beam Ø ¾” Washer Main Seat Support Cross Brace Ø 5/8” Washer Crutch M12 Aircraft Nut Leg Developer Front Post Backrest Incline Support Weight Post Backrest Support M10 Aircraft Nut Bent Bracket Small Bent Bracket Foam Tube Backrest Board Seat... -
Page 13: Warranty
LIMITED WARRANTY Escalade warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of two years on the frame and one year on all other parts and components from the date of purchase. This warranty extends only to the original purchaser.
