RTC Alarm(Only in AC mode)
S0 Press Lid switch / Sleep Button (Fn+F2) / Power Button
(depends on ACPI OS setting)
User selects the Standby Option in the Windows Shut
Down menu
ACPI OS timer expired
Critical /Low battery (depends on ACPI OS setting)
S0 Press Lid switch/ Sleep Button (Fn+F2) / Power Button
(depends on ACPI OS setting)
User selects the Hibernate Option in the Windows Shut
Down menu
Critical /Low battery (depends on ACPI OS setting)
S0 Press Lid switch / Power Button (depends on ACPI OS
setting)
The Power Button is pressed for 4 seconds (Power Button
Override)
User selects the Shut down Option in the Windows Shut
Down menu
Critical /Low battery (depends on ACPI OS setting)
Thermal critical shutdown performed by EC firmware
Note1: The backlight of LCD should be off when WOL from S3 as it is remote wake up.
Note2: the S3 -> S4 transition results in the system transitioning to the S0 state first so OS can
save the context to the hard disk. The system BIOS/KBC will not be involved for S3 -> S4
transition. The system power scheme will wake the machine from S3 and then transition to S4
Hibernation. The backlight of LCD is off during this transition.

4.7.5 Storage Devices and Batteries

Possible storage devices are FDD, HDD, CD-ROM and DVD-ROM
Floppy Disk and Hard Disk, CD-ROM and DVD-ROM
•
The BIOS must report the correct types of these devices if the drive is installed in the
system during POST. Two devices, which belong to the same category, are not
supported in this notebook.
Batteries
•
The BIOS must follow ACPI specification and report the correct number of the
installed battery and status.
S3
S4
S5
