Left Side

The following picture shows the left side of your notebook.

1.1.7 AC Adapter Connector

Use this connector to attach the AC adapter to your notebook. You can connect an AC
adapter when your notebook is switched on or off.
While the AC adapter works with electrical outlets worldwide, power connectors and power
strips vary by country. Ensure you use a compatible cable or correctly connect the cable to
the power strip or electrical outlet. Failure to do so may cause fire or damage to equipment.

1.1.8 USB Ports

Use this port to connect a USB device, such as a mouse, external keyboard, or printer to
the computer.
USB is a peripheral expansion standard that supports data-transfer rates up to 480 Mbps.
USB peripherals have a single standard for cables and connectors. You can install and
remove USB devices while the computer is on. This is called "hot swapping".
1 DC-IN
2 HDMI
3 1394(Option)
4 eSATA
5 USB2.0
6 New Card
19
