Right Side

The following picture shows the right side of your notebook.

1.1.9 USB Ports

Use this port to connect a USB device, such as a mouse, external keyboard, or printer to
the computer.
USB is a peripheral expansion standard that supports data-transfer rates up to 480 Mbps.
USB peripherals have a single standard for cables and connectors. You can install and
remove USB devices while the computer is on. This is called "hot swapping".
1.1.10 Kensington Lock (
A Kensington Security Slot is a small, metal-reinforced hole found on almost all small or
portable computer and electronics equipment, particularly on expensive and/or relatively light
ones, such as laptops, computer monitors, desktop computers, gaming consoles, and video
projectors. It is used for attaching a lock-and-cable apparatus, in particular those from
Kensington.

1.1.11 AC Adapter Connector

Use this connector to attach the AC adapter to your notebook. You can connect an AC
adapter when your notebook is switched on or off.
1 Smart Card
2 ODD lED
3 ODD Button
4 Power USB Button
5 Power USB*2
Kingston Lock
6
)
20
