USB 3.0 Dual 3.5" SATA HDD RAID Enclosure
with UASP & Fast Charge USB Hub
S352BU33HR
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 06/24/2014
*actual product may vary from photos
Advertisement
Table of Contents
Related Manuals for StarTech.com S352BU33HR
Summary of Contents for StarTech.com S352BU33HR
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 06/24/2014...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Table Of Contents
Table of Contents Product Diagram ..................1 Front View ..............................1 Rear View ..............................1 Introduction ....................2 Packaging Contents ..........................2 System Requirements ..........................2 Hardware Installation ................3 Technical Support ..................8 Warranty Information ................8 Instruction Manual... -
Page 4: Product Diagram
Product Diagram Front View Front Bay Power LED Drive Activity LEDs USB 3.0 Hub + Charging Ports Power Button Rear View RAID Mode Switch Set RAID button Drive Fan USB 3.0 port Power adapter port Instruction Manual... -
Page 5: Introduction
Introduction Packaging Contents • USB 3.0 Hard Drive Enclosure (S352BU33HR) • USB 3.0 Cable • Universal Power Adapter (NA/UK/EU) • Instruction Manual System Requirements • 1x Computer system with available USB 3.0 (5 Gbit/s) port/USB 2.0 port (480Mbps) • Microsoft® Windows® 2000/XP/Server 2003/Vista/Server 2008 R2/7/8 (32/64- bit), Apple®... -
Page 6: Hardware Installation
Hardware Installation WARNING! Hard drives and storage enclosures require careful handling, especially when being transported. If you are not careful with your hard disk, lost data may result. Always handle your hard drive and storage device with caution. Be sure that you are properly grounded by wearing an anti-static strap when handling computer components or discharge yourself of any static electricity build-up by touching a large grounded metal surface (such as the computer case) for several seconds. - Page 7 2. To reveal the drive bay, grasp the front panel and slide it upward. 3. With the hard drive label facing upward, gently slide each of your 3.5” hard drives into the drive bays until you feel resistance. Instruction Manual...
- Page 8 4. Slide the front panel back onto the S32BU33HR the same way it was removed. 5. Using a Philips head screw driver (not included), replace the side mounted screw on the left front facing side of the enclosure. Instruction Manual...
- Page 9 Adjust the RAID Control Switch to your desired RAID configuration (See Available RAID Configurations). c) Press and hold the set RAID button while turning on the S352BU33HR on by pressing the Power Button. Note: RAID configuration is only required for initial configuraiton or if you would like to change your RAID configuration.
- Page 10 Available RAID Configurations The S352BU33RER enclosure supports 4 different RAID configurations. RAID is a storage technology that combines multiple hard drives into a single unit for secure data redundancy, increased volume size and/or improved performance. Descriptions and benefits for each available RAID configuration are listed below: JBOD - Normal In JBOD, no RAID configuration is set and both drives appear as individual disks.
-
Page 11: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 12 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
