Overview
Before you begin, you should have a powerline network already set up, with
your router connected to a Powerline Adapter. The following instructions
describe how to connect the Powerline Network Adapter (model number:
PLTE200) to a computer or other network device.
Internet
Modem
Installation
A.
Connect one end of an Ethernet
network cable to the Ethernet
port of the Adapter.
Powerline
Network Adapter
Powerline
Network Adapter
Router
Diagram of a Typical Powerline Network
Computer
Gaming Console
Powerline 4-Port
Network Adapter
Connect Ethernet Network Cable
Computer
