Installing the Printer

For information on installing the printer, see the
Installation Guide
www.datamax-oneil.com.

Using the Ribbon

Ribbon Guidelines

In the event of a jam to or under the ribbon, replace
the ribbon immediately. If the jam continues, do not
remove the smear guards.

Installing the Ribbon

1. Remove the ribbon from its packaging.
2. Open the printer's cover. Verify the control panel is
facing toward you.
3. Remove the orange "Open Printer" label from the
locking lever (Figure 1).
4. Slide the printhead away from the edge of the
printer (Figure 2).
Figure 1
5. Hold the ribbon by the flat handle (Figure 3).
RP SERIES OF PRINTERS USER'S GUIDE
, which is accessible from
Open
Printer
label
2
Figure 2
RP
