RP SERIES OF PRINTERS USER'S GUIDE
Caution: (For US/Canada) Please only use the
Datamax-O'Neil part number 220180-100 power
supply with this product.

Using a Power Supply or Power Adapter

Routing the AC Power Adapter
1. Open the printer's cover. Verify the control panel is
facing toward you.
2. Depress the locking lever to open the print
mechanism (Figure 10).
3. Place the AC power adapter into the printer's
adapter cavity (Figure 11).
Figure 10
4. Feed the AC power adapter's cable through the
access hole in the printer's cigarette adapter pocket
(Figure 12).
Note: Verify the AC power adapter's cable sits flats and
does not interfere with closing the printhead mechanism
(Figure 13).
Locking
lever
Figure 11
7
