Operating Instructions (compact)
1.1
Components of the product
Numbe
Name
r
1
SIMATIC Panel PC 577
1
Restore DVD
1
Documentation and Drivers CD
1
Operating Instructions (compact)
SIMATIC Panel PC 577
6 / 8
Clamp
1
AC power cable
1
Lock for mains connector
1
Card retainer
1
Paper template
1.2
Device identification data
Enter the identification data of the device in the table:
Serial number (on the rating plate)
Order number of the device
For the Windows 2000 / XP Professional variants:
Microsoft Windows Product Key from the "Certificate of Authenticity" (COA).
The COA label is attached to the device
Ethernet address: BIOS setup (F2 key) under Main > Hardware Options > Ethernet
Address
1.3
Product documentation
The detailed operating instructions for Panel PC 577 can be downloaded as a PDF file on
the internet under the following address: http://www4.ad.siemens.de
SIMATIC Panel PC 577
Operating Instructions, Release 04/2006, A5E00795255
Description
Contains a hard disk image file with the original software (operating system
with installed hardware drivers).
Contains the documentation and the hardware drivers.
Print copy of the Operating Instructions (compact) SIMATIC Panel PC 577
Mounting bracket for the SIMATIC Panel PC 577.
Device with 12"/15" display: 6 pieces
Device with 19" display: 8 pieces
Power cable for 110 / 230V AC power supply.
Lock for AC power cable
Retainer for mounting PCI modules
Template for preparing the mounting cut-out
