1.6
Connecting
1.6.1

Connection elements and operator controls

Connection elements and operator controls of the computer unit
Location of connection elements and operator controls
SIMATIC Panel PC 577
Operating Instructions, Release 04/2006, A5E00795255
Item
Name
(1)
110/230 V AC
(2)
On / Off switch
(3)
Soft power key
(4)
PCI slots
(5)
Equipotential
bonding
(6)
Interfaces
Operating Instructions (compact)
1.6 Connecting
Description
Connection for the AC power
supply
-
See below
3 slots for PCI expansion
modules
Connection for low-resistance
grounding connection
-
1-9
