- Page 1 Instruction Manual book SPECIFICATION Wingspan : 3,400 mm 133.86 in. Length 1,450 mm 57.09 in. Weight 3,0 kg 6.6 Lbs. Radio 05 channels. HS485 HB ( 4,8 kg/cm) - BMS 631MG (5 kg/cm) Servo 05 servos HS85 BB MG ( 3,0 kg/cm) - BMS 380MG (3,6 kg/cm) Mini servo : 02 Servos Made in Vietnam.
-
Page 2: Instruction Manual
Instruction Manual Item code: BH88 This instruction manual is designed to help you build a great flying aeroplane. Please read this manual thoroughly before starting assembly of your MINIMOA. Use the parts listing below to identify all parts. WARNING. Please be aware that this aeroplane is not a toy and if assembled or used incorrectly it is capable of causing injury to people or property. -
Page 3: Safety Precaution
MINIMOA - INSTRUCTION MANUAL Item code: BH88. + Do not flip the propeller with your fingers. SAFETY PRECAUTION. + Keep loose clothing and wires away from + This is not a toy the propeller. + Be sure that no other flyers are using your + Do not start the engine if people are near. -
Page 4: Installing The Aileron Servos
MINIMOA - Instruction Manual Item code: BH88 C/A glue I. AILERON. 1.INSTALLING THE AILERON SERVOS. 1) Install the rubber grommets and brass eyelets onto the aileron servos. C/A glue C/A glue Bottom side Aileron C/A glue C/A glue Aileron Bottom side 2) Using a modeling knife, remove the cov- ering at possition show below. - Page 5 MINIMOA - INSTRUCTION MANUAL Item code: BH88. Remove covering 2x10mm. Secure 3) Using the thread as a guide and using masking tape, tape the servo lead to the end Secure of the thread: carefully pull the thread out. When you have pulled the servo lead out, re- move the masking tape and the servo lead from the thread.
-
Page 6: Installing The Aileron Linkages
MINIMOA - Instruction Manual Item code: BH88 Repeat the procedure for the other wing half. 3.INSTALLING THE AILERON LINKAGES. Installing the aileron linkages as pictures below. M2 lock nut 650 mm Top side... - Page 7 MINIMOA - INSTRUCTION MANUAL Item code: BH88. C/A glue C/A glue C/A glue C/A glue Servo tray. Top side...
- Page 8 MINIMOA - Instruction Manual Item code: BH88 Secure. Bottom side. Connector. Connector. C/A glue Secure. 3x10mm.
-
Page 9: Elevator Installation
MINIMOA - INSTRUCTION MANUAL Item code: BH88. Bottom side ELEVATOR INSTALLATION. SERVO INSTALLATION. 1. Install the rubber grommets and brass collets into the elevator servo. Test fit the servo into the servo tray. C/A glue 2. Mount the servo to the tray using the mounting screws provided with your radio sys- tem. - Page 10 MINIMOA - Instruction Manual Item code: BH88 C/A glue Secure. Bottom side ELEVATOR CONTROL HORN PUSHROD INSTALLATION. Elevator control horn install as same as the C/A glue way of aileron control horn. Please see pic- tures below. M3 lock nut.
-
Page 11: Elevator Pushrod Installation
MINIMOA - INSTRUCTION MANUAL Item code: BH88. Elevator E l e v a t o r pushrod pushrod Elevator control horn. ELEVATOR PUSHROD INSTALLATION. Elevator pushrod install as same as the way of aileron pushrod. M2 lock nut. -
Page 12: Vertical Installation
MINIMOA - Instruction Manual Item code: BH88 VERTICAL INSTALLATION. Rudder servo install as same as method of elevator servo. See picture below: C/A glue C/A glue C/A glue C/A glue Using a modeling knife cut away the cover- ing from the end of fuselage for the rudder... -
Page 13: Rudder Control Horn Installa- Tion
MINIMOA - INSTRUCTION MANUAL Item code: BH88. RUDDER PUSHROD INSTALLATION. RUDDER CONTROL HORN INSTALLA- TION. Rudder pushrod install as same as the way of aileron pushrod. Rudder control horn install as same as the way of aileron control horn. Please see pic- tures below. -
Page 14: Servo Installation
MINIMOA - Instruction Manual Item code: BH88 SERVO INSTALLATION. INSTALLING THE RECEIVER AND BATTERY. 1. Plug the servo leads and the switch lead into the receiver. You may want to plug an aileron extension into the receiver to make plugging in the aileron servo lead easier when you are installing the wing . -
Page 15: Wing Attachment
MINIMOA - INSTRUCTION MANUAL Item code: BH88. WING ATTACHMENT. Locate the carbon tube wing dihedral brace. *** Test fit the carbon tube dihedral brace into each wing haft. The brace should slide in eas- ily. If not, use 220 grit sand around the edges and ends of the brace until it fits properly. - Page 16 MINIMOA - Instruction Manual Item code: BH88 Right wing. C/A glue. Cut. Plastic parts of rudder and elevator pushrod. C/A glue Cut.
- Page 17 MINIMOA - INSTRUCTION MANUAL Item code: BH88. Top side. CANOPY AND PILOT. Cut. Epoxy glue. C/A glue C/A glue Epoxy glue.
- Page 18 MINIMOA - Instruction Manual Item code: BH88 Top side. C/A glue BALANCING. 1) It is critical that your airplane be bal- anced correctly. Improper balance will cause your plane to lose control and crash. C/A glue THE CENTER OF GRAVITY IS LOCATED 110MM BACK FROM THE LEADING EDGE OF THE WING.
-
Page 19: Pre-Flight Check
6) Properly balance the propeller. We wish you many safe and enjoyable flights with your MINIMOA. CONTROL THROWS. 1) We highly recommend setting up a plane using the control throws listed. - Page 20 MINIMOA - Instruction Manual Item code: BH88 Accessories of wood box. Epoxy glue. Epoxy glue. C/A glue C/A glue...
- Page 21 MINIMOA - INSTRUCTION MANUAL Item code: BH88.
