SAFETY NOTICE:
If this appliance is not properly installed, a house fire
may result. For your safety, follow the installation
directions. Contact local building or fire officials about
restrictions and installation inspection requirements
in your area.
Copyright 2007, T.I.
$10.00
93508133
4050124
Pendleton
(745/790)
Owner's
Manual
• Freestanding Stove
• Mobile-Home Approved
• Alcove Approved
• Hearth-Stove Approved
• Masonry Fireplace
Insert
• Zero-Clearance (Metal)
Fireplace Insert
Listed
Tested to: U.L. 1482
Advertisement
Table of Contents
Related Manuals for Travis Industries Avalon Pendleton 745
Summary of Contents for Travis Industries Avalon Pendleton 745
- Page 1 Pendleton (745/790) Owner's Manual • Freestanding Stove • Mobile-Home Approved • Alcove Approved • Hearth-Stove Approved • Masonry Fireplace Insert • Zero-Clearance (Metal) Fireplace Insert SAFETY NOTICE: If this appliance is not properly installed, a house fire may result. For your safety, follow the installation directions.
-
Page 2: Introduction & Important Information
We suggest 1/24/05that you attach your Bill of Sale to this page so that you will have all Purchased From: the information you need in one place should the need for service or information occur. Travis Industries 93508133 4 050124... -
Page 3: Table Of Contents
Insert with Face Seal Connection......22 Warranty Warranty ............35 Listing Information Listing Information..........36 Optional Equipment Stove Legs ............37 Pedestal............37 Rear Blower Installation........39 Outside Air Boot Installation .........40 Surround Panels ..........41 Front Blower .............43 I n d e x Index ...............44 Travis Industries 93508133 4 020509... -
Page 4: Travis Industries
Creosote may build up and residential type chimney or Liner cause a house fire. an approved masonry • Do not connect this chimney with a standard appliance to any chimney clay tile, or stainless steel serving another appliance. liner. Travis Industries 93508133 4 020509... -
Page 5: Safety Precautions
Avoid placing wood against the glass when loading. Do not slam the door or strike the glass. • Do not throw this manual • Travis Industries, Inc. away. This manual has grants no warranty, This important operating and implied or stated, for Manual... -
Page 6: Features & Specifications
** ZC (metal) fireplaces require 12-5/8". Depth into Fireplace** ..11-5/8" *** ZC (metal) fireplaces require 25-3/4". Onto Hearth**** ....4-3/4" **** Does not include hearth protection. 16-3/8" Emissions: 3.0 Grams Per Hour (EPA Phase II Approved) – Tests conducted by E.E.S.P.C. Travis Industries 93508133 4 020509... -
Page 7: Stove Installation
Planning The Installation We suggest that you have an authorized Travis Industries dealer install your stove. If you install the stove yourself, your authorized dealer should review your plans for installation. Check with local building officials for any permits required for installation of this stove and notify your insurance company before proceeding with installation. -
Page 8: Floor Protection Requirements
Stove Installation (for qualified installers only) Floor Protection Requirements • Stove must be placed on the Travis Industries legs or Pedestal. • Must be non-combustible and at least .018" thick (26 gauge) Floor protection must be non-combustible and at least .018"... -
Page 9: Stove Placement Requirements
Offsets must be used to maintain the stove to wall clearance. NOTE : Reduced clearance connectors may not connect to the flue collar – order an appliance adapter for the connector being used. Travis Industries 93508133 4 020509... -
Page 10: Chimney Requirements
This appliance relies upon natural draft to operate. External forces, such as wind, Performance barometric pressure, topography, or factors of the home (negative pressure from exhaust fans, chimneys, air infiltration, etc.), may adversely affect draft. Travis Industries can not be responsible for external forces leading to less than optimal performance. •... -
Page 11: Chimney Termination Requirements
15' and at least 16 square inches in cross section) Air may be drawn from a ventilated Outside air entrance must be placed so crawl space or use an air duct. it does not become blocked by snow. Travis Industries 93508133 4 020509... -
Page 12: Alcove Installation Requirements
All other alcoves are considered combustible. The clearances below must be met: Non-combustible alcove construction (on walls and ceiling) - see the explanation above. Ventilated air space 3 1/2" thick non- combustible material 1" Min. Non-combustible reinforcer Travis Industries 93508133 4 020509... -
Page 13: Mobile Home Requirements
The appliance must be grounded to the chassis of the Clearance mobile home (consult your building official). (as outlined above) WARNING: DO NOT INSTALL IN SLEEPING ROOM. CAUTION: THE STRUCTURAL INTEGRITY OF THE MOBILE HOME FLOOR, WALL, AND CEILING/ROOF MUST BE MAINTAINED. Travis Industries 93508133 4 020509... -
Page 14: Installation Diagrams Standard Ceiling With A Factory Built Chimney
(some require a radiation usually 2") shield). Minimum 15' Chimney Maximum 33' Connector Sections Floor Protection Stove Clearances (See the section "Floor (See the section "Stove Protection Requirements" Placement Requirements" for more details) for more details) Travis Industries 93508133 4 020509... -
Page 15: Exterior Factory Built Chimney
Remove damper manufacturer's or wire it open Floor Protection instructions for (See the section installation and "Floor Protection See the section support. Requirements" "Stove Placement for more details) Requirements" for minimum clearances required. Travis Industries 93508133 4 020509... -
Page 16: Hearth Stove Direct Connection
(U.L. (U.L. Listed) wall thimble. Listed) wall Chimney connector sections thimble. See the section Make sure the "Floor Protection clean-out seals in Requirements" place. Travis Industries 93508133 4 020509... -
Page 17: Insert Installation
Planning The Installation We suggest that you have an authorized Travis Industries dealer install your stove. If you install the stove yourself, your authorized dealer should review your plans for installation. Check with local building officials for any permits required for installation of this stove and notify your insurance company before proceeding with installation. -
Page 18: Insert Size Requirements
(dimension "x"). Hearth Requirements • Must extend 16" in front of the insert and 8" on both sides • Must be non-combustible 1/4" thick insulating board with a thermal conductivity of K = 0.72 Travis Industries 93508133 4 020509... -
Page 19: Masonry Fireplace Requirements
This appliance relies upon natural draft to operate. External forces, such as wind, barometric pressure, topography, or factors of the home (negative pressure from exhaust fans, chimneys, air infiltration, etc.), may adversely affect draft. Travis Industries can not be responsible for external forces leading to less than optimal performance. -
Page 20: Block-Off Plate Installation
Measurement "C" The center of the flue is 9 1/4" back from the Measurement "B" fireplace Firebox opening. The center of the flue is 9 1/4" back from the fireplace opening (6 1/4" in diameter). Travis Industries 93508133 4 020509... -
Page 21: Insert With Positive Connection
Remove (see "Block-off Surround Panels damper Plate Installation" or wire it on page 20). open See the section "Insert Placement Block-off plate or Requirements" for damper adapter minimum clearances and hearth required. Travis Industries 93508133 4 020509... -
Page 22: Insert With Direct Connection (Zc Fireplace)
"Surround Panel Panels" installation instructions in the back of Installation" on the manual) page 42). Airtight Insulated Clean-Out See the section "Insert Placement Requirements" for minimum clearances and hearth required. Remove damper or wire it open Travis Industries 93508133 4 020509... -
Page 23: Operating Your Appliance
The door becomes hot during use. Use a glove to open the door if the handle is hot. To prevent smoke from entering the room, open the door a small amount and let air enter the firebox. This stabilizes the air flow before opening the door completely. Travis Industries 93508133 4 020509... -
Page 24: Starting A Fire
This should start the chimney drafting (this eliminates "cold air blockage"). Use plenty of kindling to ensure the stove reaches a proper temperature. Once the kindling is burning rapidly, place a few larger pieces of wood onto the fire. Travis Industries 93508133 4 020509... -
Page 25: Adjusting The Burn Rate
If the ashes are disposed of by burial in soil or otherwise locally ASHES dispersed, they should be retained in the closed container until all cinders have thoroughly cooled. Travis Industries 93508133 4 020509... -
Page 26: Optional Blower Operation
- this is normal. Blower Sounds: The blower will make a slight "humm" as it pushes air through the stove. Hint: Make sure the leveling bolts on legs are extended - preventing the hearth from amplifying any vibrations. Travis Industries 93508133 4 020509... -
Page 27: Hints For Burning
Wood Cutting and Storage Cut wood to length and Store the wood off the ground in a chop into quarters. covered area. Allow for airflow Air Flow around the wood to dry the wood. Air Flow Air Flow Travis Industries 93508133 4 020509... -
Page 28: Troubleshooting
Glass Inspection" on page 30 for details. • Check the ash bed for coals. Often, coals are still glowing under a slight bed of flyash. By raking these into a pile you can re-start your stove quickly. Travis Industries 93508133 4 020509... -
Page 29: Maintaining Your Appliance
The ash acts as a light abrasive. The glass will develop a very slight haze over time. This is normal and will not affect viewing of the fire. Travis Industries 93508133 4 020509... -
Page 30: Monthly Maintenance
The door must form an air-tight seal to the firebox for the stove to work correctly. Inspect the door gasket to make sure it forms an air-tight seal to the firebox. The door can be lifted off the hinges if extensive repairs are conducted. Travis Industries 93508133 4 020604... -
Page 31: Yearly Maintenance
Slight scaling or rusting of the metal is normal. Make sure the push pins hold the air tubes in place. Floor and Wall Firebricks - replace any severely damaged firebrick along the side or floor of the firebox. Travis Industries 93508133 4 020509... -
Page 32: Door Parts
You may need to open and close the door repeatedly to get the gasket to seat fully. Replacing the Door Handle The door handle consists of several components. See the illustration above for a component list. For details on adjusting the door see page 30. Travis Industries 93508133 4 020509... -
Page 33: Firebox Parts
Do not pry firebrick - they chip and crack easily. Remove the floor firebricks first. The side firebrick are removed later because they are pinned in place by the floor firebrick. Clean the firebox prior to replacing the firebrick. Travis Industries 93508133 4 060417... -
Page 34: Baffle Removal And Replacement
5. Remove the baffle support by feeding it through the space between secondary air tube and the door. REPLACEMENT INSTRUCTIONS: Follow the instructions in reverse order. Make sure the front baffle support is properly aligned Travis Industries 93508133 4 020509... -
Page 35: Warranty
2. Travis Industries has the option of either repairing or replacing the defective component. 3. If your dealer is unable to repair your appliance’s defect, he may process a warranty claim through TRAVIS INDUSTRIES, INC., including the name of the dealership where you purchased the appliance, a copy of your receipt showing the date of the appliance’s purchase, and the serial number on your... -
Page 36: Listing Information
Listing Label Travis Industries 93508133 4 070821... -
Page 37: Optional Equipment
The lag bolts and washers may be inserted through these holes to anchor the pedestal to the floor. Pedestal The dowels insert onto the front and back edge of the pedestal base. Travis Industries 93508133 4 020509... - Page 38 Rear Blower Knock-Outs The cover plate seals the area around the air control rod. Remove the two screws and bridge from the cover plate. Slide the cover plate underneath the air control rod and re-attach the bridge. Travis Industries 93508133 4 020509...
- Page 39 Remove the two screws that hold the bridge to the cover plate. Then replace Air Control the bridge when the cover plate is in place. The cover plate has a clip which attaches it underneath the air control. Travis Industries 93508133 4 020509...
-
Page 40: Rear Blower Installation
Attach the quick-connects leading from the snap disk to the Plug the power cord into a 110 V. outlet after installing the quick-connects from the blower blower. (orientation does not matter). Travis Industries 93508133 4 020509... - Page 41 The hole in the floor (and hearth) must be a minimum 16 square inches. It should be 1/2” smaller than the footprint of the air boot in each dimension to allow for the Floor (and hearth) gasket to seal. Travis Industries 93508133 4 020509...
-
Page 42: Surround Panels
Optional Knock-Out An optional knock-out is provided on both Install the top panel so the tabs insert sides if the power cord is routed behind the into the joggle clips on the top panel surround panel. Travis Industries 93508133 4 051104... -
Page 43: Front Blower
Baseplate of Appliance (Below Ashlip) Front of Insert the baseplate his clip aligns the blower of the appliance into Appliance nside the convection channel. this gap. Travis Industries 93508133 4 020509... -
Page 44: Index
Floor Protection Requirements (stove) ....8 Floor Protection Requirements (insert)....18 Glass Cleaning ..........29 Glass Replacement ........32 Hearth (Floor Protection - Stove) ......8 Hearth (Floor Protection - Insert).......18 Hearth Stove ..........15 Heating Specifications ........6 Hints for Burns..........27 Installation Options ........6 Travis Industries 93508133 4 020509...
