The audio base contains the following additional items.
• Audio Base
• Captive Audio Cable
• Audio Base Manual
• Power Cord

Quick Start

If the audio base is not attached to the monitor, please use the following
steps to attach the audio base to the monitor.
If the audio base is already attached to the monitor proceed to Step 1-B.
STEP 1-A.
STEP 2-A.
100
95
75
25
5
0
MAKE SURE THE MONITOR IS DISCONNECTED FROM THE
SYSTEM AND IS UNPLUGGED FROM THE WALL OUTLET
BEFORE ANY WORK IS DONE ON THE MONITOR.
With the monitor unplugged from your system and the
wall outlet, carefully turn the monitor upside down on a
firm table (Figure 1-A).
Position the locking
tabs on the audio
base with the holes
in the monitor and
slide the audio base
in place (Figure 2-A).
Firm Table
Figure 1-A
E - 1
Bottom of
monitor
Top of monitor
