Quick Start

To attach the MultiSync FE700+ monitor to your
system, follow these instructions:
1. Turn off the power to your computer and MultiSync monitor.
2. If necessary, install the display card. For more information, refer to
the display card manual.
3. For PC: Connect the 15-pin
mini D-SUB of the captive
signal cable to the connector
for the display card in your
system (Figure A.1). Tighten
all screws.
4. Connect one end of the power
cord to the MultiSync FE700+
monitor and the other end to
the power outlet (Figure B.1).
01c_english
Captive Signal Cable
Power Outlet
English-2
2
15-pin mini D-SUB
Figure A.1
Power
Cord
Figure B.1
