Page 3: Quick Start
• Power Cord Quick Start If the audio base is not attached to the monitor, please use the following steps to attach the audio base to the monitor. If the audio base is already attached to the monitor proceed to Step 1-B. - Page 4 (Figure 3-A). Figure 3-A Figure 2-A STEP 1-B. Connect one end of the short power cord to the connector on the audio base and the other end to the monitor (Figure 1-B). AC OUT Short Power Cord Figure 1-B STEP 2-B.
- Page 5 AC IN Short Power Cord Long Power Cord Figure 3-B STEP 4-B. Reconnect your monitor to your computer system as shown in the monitor User’s Manual. STEP 5-B. Turn on the audio base and adjust the controls for best sound performance.
-
Page 6: Specifications
Specifications Speakers Two 2.2 inch / 57mm full range Power 1 + 1 Watts @ 8 Ohms with 10% THD ≥ 10k Ohms Input Impedance Input Sensitivity 500mV input for full output Frequency response 150Hz - 10kHz Power Requirements AC 100-240V Current Rating 3.15A (Audio 0.15A. - Page 7 (Type H05VV-F should be used except in UK) NOTE: The audio base is to be used only with NEC MultiSync monitors. • In UK, use a BS-approved power cord with molded plug and a black (5A) fuse installed for use with this audio base.
-
Page 8: Troubleshooting
Troubleshooting Symptoms Possible Solution Note Problem No sound No power to Make sure all connecting Provided power has been from unit. plugs between the audio verified, it is possible to speakers base and computer are test to unit by fully seated. Make sure disconnecting the audio the wall power outlet or cable that is connected...
