Safety and General Information.....................................................1
FCC User Information ...............................................................1
European Compliance...............................................................3
System Components .....................................................................5
solo Desktop Charger Base...........................................................6
Mute Button ...............................................................................6
Power Module ...........................................................................6
USB Connection ........................................................................7
Headset Audio Connection........................................................7
External Audio Connection........................................................7
solo Wireless Microphone..............................................................8
Charging the Batteries...............................................................8
Using the Microphone ...............................................................9
Pairing the Microphone to the Charger Base ..........................10
Installation....................................................................................12
Computer Software Set-up......................................................12
Using with a solo Executive System .......................................15
System Functions ........................................................................16
LED Status Indications ................................................................17
Warranty ......................................................................................18
System Specifications..................................................................19
iii
LED Status Indications
The following LED patterns are shown on either the Microphone or
the Charger Base.
LED pattern Meaning
Solid GREEN Confirmation of power-up.
(Microphone only)
Solid RED Pairing mode, or confirmation of
powering-down, or battery charging.
GREEN flash every Microphone connected and un-muted.
1.5 seconds
Two RED flashes Microphone connected and muted.
every 1.5 seconds
YELLOW flash Microphone connected, battery low.
alternating with either
GREEN or two RED
flashes
Alternating RED, Searching for a connection, or out of
YELLOW, GREEN, radio range. The Microphone will try to
YELLOW (Microphone re-establish the link for about 5 minutes,
only) and then turn off automatically. The
Microphone will beep five times every
30 seconds as a reminder to bring the
Microphone closer to the Charger Base.
Alternating RED, Unpaired.
YELLOW, GREEN,
YELLOW
Rapid RED flashes Radio congestion - it is not possible to
continuing for more make a radio connection because there
than a few seconds are already too many nearby users of
the UPCS band, or there is heavy radio
interference. Other UPCS users will
include some types of digital cordless
phones, and other solo installations.
Groups of five rapid Unit is faulty. Please contact your AV
RED flashes service provider for advice.
