SPECIFICATION

CHARGER
Model
Charging time
Charging voltage
Weight
NOTE: The recharging time may vary according to the ambient temperature.

APPLICATION

For charging the HITACHI BATTERY.
○ BSL1430, BSL1830

CHARGING

Before using the power tool, charge the battery as follows.
1. Connect the charger's
receptacle.
When connecting the plug of the charger to a
receptacle, the pilot lamp will blink in red. (At 1-second
intervals).
Table 1
Before
charging
The pilot While
charging
lamp
lights or
Charging
blinks in
complete
red.
Charging
impossible
The pilot
lamp
Overheat
lights in standby
green.
(2) Regarding the temperature of the rechargeable
battery.
The temperatures for rechargeable batteries are
as shown in the Table 2, and batteries that have
become hot should be cooled for a while before being
recharged.
Table 2
Rechargeable batteries
BSL1430, BSL1830
(3) Regarding recharging time
Table 3 shows the recharging time required according
to the type of battery.
power cord to
Indications of the pilot lamp
Lights for 0.5 seconds. Does not light for
Blinks 0.5 seconds. (off for 0.5 seconds)
Lights continuously
Lights
Lights for 0.5 seconds. Does not light for
Blinks 0.5 seconds. (off for 0.5 seconds)
Lights for 0.1 seconds. Does not light for
Flickers 0.1 seconds. (off for 0.1 seconds)
Lights continuously
Lights
Temperatures at which the
battery can be recharged
0°C — 50°C
UC18YRSL
Approx. 45 minutes (at 20°C)
14.4 V – 18 V
0.6 kg
2. Insert the battery into the charger.
Firmly insert the battery into the charger until the line is
visible, as shown in Fig. 1, 2.
3. Charging
When inserting a battery in the charger, the charge
status lamp will light up continuously in red.
When the battery becomes fully recharged, the
pilot lamp will blink in red. (At 1-second intervals.)
the
(See Table 1)
(1) Lamp indication
The indications of the pilot lamp will be as shown in
Table 1, according to the condition of the charger or
the rechargeable battery.
Table 3 Recharging time (approx. min.) at 20°C
Battery
Voltage
14.4 V
18 V
NOTE: The recharging time may vary according to the
ambient temperature.
4. Disconnect the charger's power cord from the
receptacle.
5. Hold the charger fi rmly and pull out the battery.
NOTE
Be sure to pull out the battery from the charger after
use, and then keep it.
Malfunction in the
battery or the charger
Battery overheated.
Unable to charge.
(Charging will commence
when battery cools)
Battery capacity (Ah)
Li-ion BATTERY
3.0 Ah
BSL1430
45 min.
(8 cells)
BSL1830
45 min.
(10 cells)
