Product Specifications - Samsung AQV09VBA Service Manual

2-2 Product Specifications

Item
Type
Capacity
Running Frequency
Dehumidifying
Performance Air Volume
Noise
Energy Efficiency
Ratio
Power
Power Consumtion
Operating Current
Power
Power Factor
Power Cord
Outer Dimension
Weight (Net)
Refrigerant Pipe
Drain Hose
Size
Compressor
Oil Type
Blower
Heat Exchanger
Refrigerant Control Unit
Freezer Oil Capacity
Refrigerant to Change (R410A)
Protection Device (OLP)
Cooling Test Condition
Heating Test Condition
Operation conditon range
2-2
141 Kinderkamack Rd, Park Ridge, NJ 07656 Tel: 201-782-1782 Fax: 201-782-1783 Web: www.amgair.com Email: info@amgair.com
Model
Cooling
kW
(Low / Std / Max)
Heating
Cooling
Hz
(Low / Std / Max)
Heating
ℓ/h
Cooling
㎥/min
(H/M/L)
Heating
Cooling
dB
(H/L)
Heating
Cooling
W/W
(Std)
Heating
ph-V-Hz
Cooling
W
(Low / Std / Max)
Heating
Cooling
A
(Low / Std / Max)
Heating
Cooling
%
(Low / Std / Max)
Heating
Length m
Number of Core Wire
Capacity A
Width x Height x Depth mm
kg
Liquid mm x L(m)
Gas mm x L(m)
D x L(mm)
Type
Type
Motor
Rated Output
Type
Type
Motor
Rated Output W
cc
g
indoor
cooling
Outdoor
indoor
heating
Outdoor
Air Marketing Group LLC
AQV09VBC
Indoor Unit Outdoor Unit
Wall-mounted
0.99 / 2.50 / 3.20
0.99 / 3.50 / 4.50
20 / 46 / 61
20 / 66 / 85
1.4
8.6/8.1/7.6 28
9.5/8.9/8.3 27
41/25 51
41/25 51
4.10
4.10
1-220/240-50
240 / 610 / 840
200 / 853 / 1450
1.5 / 3.0 / 4.0
1.4 / 4.5 / 6.0
70 / 85 / 90
70 / 85 / 90
2
3
10
825 X 285 X 189 790 X 548 X 285
9.0 32.6
Φ6.35 x 5
Φ9.52 x 5
Φ18 x 550
Rotary, G4C090LUDER
Hermetic
853W
FREOLα68ES-T
Cross-flow Propeller
Resin / Steel, AC Resin / Steel, DC
27 25
2 Row 14 Step 1 Row 24 Step
EEV
320
900
None
Indoor Unit : DB27°C WB 19°C
Indoor Unit : DB20°C WB 15°C
16°C ~ 32°C
-10°C ~ 43°C
-15°C ~ 30°C
-15°C ~ 24°C
AQV12VBC
Indoor Unit Outdoor Unit
Wall-mounted
0.99 / 3.50 / 4.00
0.99 /4.00 / 5.20
20 / 71 / 81
20 / 77 / 95
1.6
8.9/8.3/7.6 28
10/9.4/8.8 27
43/25 53
43/25 53
3.40
3.64
1-220/240-50
240 / 1030 / 1200
200 / 1100 / 1600
1.5 / 4.8 / 5.8
1.4 / 5.2 / 7.0
70 / 90 / 90
70 / 90 / 90
2
3
10
825 X 285 X 189 790 X 548 X 285
9.0 32.6
Φ6.35 x 5
Φ9.52 x 5
Φ18 x 550
Rotary, G4C090LUDER
Hermetic
853W
FREOLα68ES-T
Cross-flow Propeller
Resin / Steel, AC Resin / Steel, DC
27 25
2 Row 14 Step 1 Row 24 Step
EEV
320
900
None
Outdoor Unit : DB35°C WB 24°C
Outdoor Unit : DB7°C WB 6°C
16°C ~ 32°C
-10°C ~ 43°C
-15°C ~ 30°C
-15°C ~ 24°C
Samsung Electronics
