3-3 Outdoor LED Error Display and Check Method

No.
Yellow
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
Samsung Electronics
141 Kinderkamack Rd, Park Ridge, NJ 07656 Tel: 201-782-1782 Fax: 201-782-1783 Web: www.amgair.com Email: info@amgair.com
LED Display
Green Red
Air Marketing Group LLC
Explanation
Power off/ VDD NG
IPM Over Current(O.C)
Abnormal Serial communication
Compressor Starting error
Normal Operation
Compressor Lock error
DC-Link voltage under/over error
Outdoor temperature sensor error
Discharge over temperature
Discharge temperature sensor error
Current sensor error
Compressor limit error
Coil temperature sensor error
1min. Time out Communication
Fan error
OTP error
Compressor rotation error
DC-Link voltage sensor error
I_Trip error / PFC Over current
GAS Leak error
AC Line Zero Cross Signal out
Power ON reset(1sec)
Capacity miss match
LED ON, LED OFF, LED BLINK
