Icom IC-706MKIIG Service Manual page 47

[PA UNIT]
REF ORDER
NO. NO.
EP609 6910000640 FSOH090RN
EP610 6910000640 FSOH090RN
EP611 6910000640 FSOH090RN
EP612 9010000630 Tube D=10.0
MP101 8930014140 earth spring (D)
MP231 8860001130 2177 RUG
MP232 8930049100 2177 PA SPRING
MP233 8930014140 earth spring (D)
MP234 8860001130 2177 RUG
MP235 8930053490 Insulation sheet (GH)
MP241 8930050261 2177 THERMALLY SHEET-1
MP451 8510012150 2177 PA S-PLATE
MP501 8930024170 earth spring (G)
MP502 8930024170 earth spring (G)
MP601 8950000180 Cable tie -80
MP602 8950000180 Cable tie -80
MP603 8510014090 2177 DRIVER SHIELD
MP604 8510014110 2177 PA SHIELD
MP605 8950000180 Cable tie -80
MP606 8950000180 Cable tie -80
MP607 8930014140 earth spring (D)
MP608 8930027810 emboss tape (B)
MP610 8930049110 sponge (GC)
MP611 8930030380 FERRITE SHEET (C)
MP612 8930024170 earth spring (G)
MP613 8950000180 Cable tie -80
[FILTER BOARD]
REF ORDER
NO. NO.
J1 6510007900 TBP-P01X-A1
J2 6510007900 TBP-P01X-A1
J4 6450001491 HLJ7001-016010
J5 6510024661 TCS5072-1041577
J7 6450001650 HSJ0836-01-500
J8 6450001660 EX345GLB
J9* 6510020081 52808-2071
J11 6510016171 52018-8836
J12* 6510020081 52808-2071
J13 6510017150 TMP-S01X-C1
J14 6450001841 TCS7568-4320177
P1 6510003240 TMP-P01X-A1
P2 6510003240 TMP-P01X-A1
W11 9012962951 62/99/180/C24/C31
W12 9086700300 Wire 08
W21 9086700060 62/99/110/C31/C24
W22 9086700300 Wire 08
MP1 8930017200 752 earth spring
MP3 8930001170 earth spring (A) (FX-294)
MP4 8930055970 2177 GND SPRING
MP5 8930055970 2177 GND SPRING
MP6 8930055970 2177 GND SPRING
[ACCESSORIES]
REF ORDER
NO. NO.
P1 5610000410 AP-319
P2 5610000420 AP-338
†
MC1 – HM-103-1
F1 5210000090 FGB 30A
F2 5210000131 FGB 4A PBF
W1 8900006490 OPC-025D
W2 8900006110 OPC-596
EP1 0880000230 OPC-639 (EX-1874 PACKING)
EP2 6910011960 ZCAT1518-0730
MP1 8930007300 MIC hunger
*: Refer to SECTION 8 "BOARD LAYOUTS."
†
: Optional product
Screw abbreviations
A, B0, BT: Self-tapping PH: Pan head ZK: Black
NI-ZU: Nickel-Zinc SUS: Stainless
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
6 - 3
