Icom IC-706MKIIG Service Manual page 38

[PLL UNIT]
REF ORDER
NO. NO.
C602 4030006880 S.CER C1608 JB 1H 472K-T
C603 4030006880 S.CER C1608 JB 1H 472K-T
C623 4030006880 S.CER C1608 JB 1H 472K-T
C624 4030008320 S.CER C1608 UJ 1H 470J-T
C625 4030006880 S.CER C1608 JB 1H 472K-T
C626 4030008320 S.CER C1608 UJ 1H 470J-T
C641 4030006980 S.CER C1608 CH 1H 070D-T
C642 4030009520 S.CER C1608 CH 1H 020B-T
C643 4030007030 S.CER C1608 CH 1H 150J-T
C644 4030009560 S.CER C1608 CH 1H R75B-T
C645 4030006990 S.CER C1608 CH 1H 080D-T
C662 4030006880 S.CER C1608 JB 1H 472K-T
C663 4030006880 S.CER C1608 JB 1H 472K-T
C664 4030007090 S.CER C1608 CH 1H 470J-T
C665 4030006880 S.CER C1608 JB 1H 472K-T
C681 4030006880 S.CER C1608 JB 1H 472K-T
C682 4030009650 S.CER C1608 CH 1H 240J-T
C683 4030006880 S.CER C1608 JB 1H 472K-T
C684 4030006920 S.CER C1608 CH 1H 010C-T
C685 4030009650 S.CER C1608 CH 1H 240J-T
C686 4030007090 S.CER C1608 CH 1H 470J-T
C701 4030006880 S.CER C1608 JB 1H 472K-T
C711 4030007070 S.CER C1608 CH 1H 330J-T
C712 4030007010 S.CER C1608 CH 1H 100D-T
C713 4030007090 S.CER C1608 CH 1H 470J-T
C714 4030006980 S.CER C1608 CH 1H 070D-T
C715 4030007060 S.CER C1608 CH 1H 270J-T
C731 4030006880 S.CER C1608 JB 1H 472K-T
C741 4030008560 S.CER C1608 CH 1H 300J-T
C742 4030007000 S.CER C1608 CH 1H 090D-T
C743 4030007070 S.CER C1608 CH 1H 330J-T
C744 4030006960 S.CER C1608 CH 1H 050C-T
C745 4030007040 S.CER C1608 CH 1H 180J-T
C761 4030006880 S.CER C1608 JB 1H 472K-T
C771 4030007020 S.CER C1608 CH 1H 120J-T
C772 4030007110 S.CER C1608 CH 1H 680J-T
C773 4030007030 S.CER C1608 CH 1H 150J-T
C781 4030007030 S.CER C1608 CH 1H 150J-T
C782 4030006940 S.CER C1608 CH 1H 030C-T
C783 4030007060 S.CER C1608 CH 1H 270J-T
C784 4030006990 S.CER C1608 CH 1H 080D-T
C785 4030007020 S.CER C1608 CH 1H 120J-T
C791 4030006880 S.CER C1608 JB 1H 472K-T
C801 4030007050 S.CER C1608 CH 1H 220J-T
C802 4030007060 S.CER C1608 CH 1H 270J-T
C803 4030007010 S.CER C1608 CH 1H 100D-T
C804 4030007120 S.CER C1608 CH 1H 820J-T
C805 4030007040 S.CER C1608 CH 1H 180J-T
C811 4030006990 S.CER C1608 CH 1H 080D-T
C812 4030006970 S.CER C1608 CH 1H 060D-T
C813 4030007040 S.CER C1608 CH 1H 180J-T
C814 4030006930 S.CER C1608 CH 1H 020C-T
C815 4030007010 S.CER C1608 CH 1H 100D-T
C821 4030007060 S.CER C1608 CH 1H 270J-T
C822 4030007020 S.CER C1608 CH 1H 120J-T
C823 4030007010 S.CER C1608 CH 1H 100D-T
C824 4030006990 S.CER C1608 CH 1H 080D-T
C825 4030007110 S.CER C1608 CH 1H 680J-T
C826 4030006860 S.CER C1608 JB 1H 102K-T
C827 4030007060 S.CER C1608 CH 1H 270J-T
C828 4030009910 S.CER C1608 CH 1H 040B-T
C829 4030007010 S.CER C1608 CH 1H 100D-T
C830 4030006980 S.CER C1608 CH 1H 070D-T
C831 4030007010 S.CER C1608 CH 1H 100D-T
[ESP], [OTH], [ITA], [ITR], [OTH-1], [ITR-1], [CHN], [CHN-01] only
C851 4030006880 S.CER C1608 JB 1H 472K-T
C852 4030006880 S.CER C1608 JB 1H 472K-T
C853 4030011340 S.CER C1608 CH 1H 471J-T except [EUR], [FRA], [USA]
C861 4030007030 S.CER C1608 CH 1H 150J-T
C862 4030007010 S.CER C1608 CH 1H 100D-T
C863 4030009920 S.CER C1608 CH 1H 050B-T
C864 4030006990 S.CER C1608 CH 1H 080D-T
C865 4030007090 S.CER C1608 CH 1H 470J-T
C871 4030007000 S.CER C1608 CH 1H 090D-T
C872 4030009500 S.CER C1608 CH 1H 0R5B-T
C873 4030009920 S.CER C1608 CH 1H 050B-T
C874 4030009540 S.CER C1608 CH 1H 1R5B-T
C875 4030009920 S.CER C1608 CH 1H 050B-T
C876 4030006880 S.CER C1608 JB 1H 472K-T
C881 4030007100 S.CER C1608 CH 1H 560J-T
[ESP], [OTH], [ITA], [ITR], [OTH-1], [ITR-1], [CHN], [CHN-01] only
C882 4030007110 S.CER C1608 CH 1H 680J-T
[ESP], [OTH], [ITA], [ITR], [OTH-1], [ITR-1], [CHN], [CHN-01] only
C883 4030007100 S.CER C1608 CH 1H 560J-T
[ESP], [OTH], [ITA], [ITR], [OTH-1], [ITR-1], [CHN], [CHN-01] only
C884 4030009910 S.CER C1608 CH 1H 040B-T
C885 4030009910 S.CER C1608 CH 1H 040B-T
C886 4030009910 S.CER C1608 CH 1H 040B-T
C902 4030011600 S.CER C1608 JB 1E 104K-T
C903 4030011600 S.CER C1608 JB 1E 104K-T
C904 4030011600 S.CER C1608 JB 1E 104K-T
C905 4030011600 S.CER C1608 JB 1E 104K-T
C906 4030011600 S.CER C1608 JB 1E 104K-T
C907 4030011600 S.CER C1608 JB 1E 104K-T
C931 4030011600 S.CER C1608 JB 1E 104K-T
C934 4030006880 S.CER C1608 JB 1H 472K-T
C935 4030006880 S.CER C1608 JB 1H 472K-T
C941 4030006880 S.CER C1608 JB 1H 472K-T
C942 4030011600 S.CER C1608 JB 1E 104K-T
C943 4030007050 S.CER C1608 CH 1H 220J-T
except [EUR], [FRA], [ESP], [USA], [EUR-1], [ESP-1], [USA-1]
C945 4030007130 S.CER C1608 CH 1H 101J-T
C946 4030007140 S.CER C1608 CH 1H 121J-T
DESCRIPTION
[PLL UNIT]
REF ORDER
NO. NO.
C951 4030007010 S.CER C1608 CH 1H 100D-T
except [EUR], [FRA], [ESP], [USA], [EUR-1], [ESP-1], [USA-1]
C981 4030007040 S.CER C1608 CH 1H 180J-T
C982 4030007090 S.CER C1608 CH 1H 470J-T
C983 4030007040 S.CER C1608 CH 1H 180J-T
C991 4030007040 S.CER C1608 CH 1H 180J-T
C992 4030006960 S.CER C1608 CH 1H 050C-T
C993 4030007070 S.CER C1608 CH 1H 330J-T
C994 4030006930 S.CER C1608 CH 1H 020C-T
C995 4030007040 S.CER C1608 CH 1H 180J-T
C1000 4030006860 S.CER C1608 JB 1H 102K-T
C1001 4030006860 S.CER C1608 JB 1H 102K-T
C1002 4030006860 S.CER C1608 JB 1H 102K-T
C1004 4030006860 S.CER C1608 JB 1H 102K-T
C1005 4030006860 S.CER C1608 JB 1H 102K-T
C1006 4030006860 S.CER C1608 JB 1H 102K-T
RL231 6330000621 RLY
CP281 6910009670 S.CHK HK3-S-T
CP282 6910009670 S.CHK HK3-S-T
J252 6510019981 S.CNR 52808-1671 (1690)
J253 6510019971 S.CNR 52808-1071
J254 6510019071 S.CNR 52559-3072 (3092)
W43 7030003860 S.RES ERJ3GE JPW V
[OTH], [ITA], [ITR], [OTH-1], [ITA-1], [ITR-1], [CHN], [CHN-01] only
W294 9034704001 WIR
W301 7030003860 S.RES ERJ3GE JPW V
W461 7030003860 S.RES ERJ3GE JPW V
[OTH], [ITA], [ITR], [OTH-1], [ITA-1], [ITR-1], [CHN], [CHN-01] only
W592 7030003860 S.RES ERJ3GE JPW V
W661 7030003860 S.RES ERJ3GE JPW V
except [EUR], [FRA], [ESP], [USA], [EUR-1], [ESP-1], [USA-1]
W993 7030003860 S.RES ERJ3GE JPW V
EP2 6910012350 S.BEA
[ESP], [OTH], [ITA], [ITR], [OTH-1], [ITR-1], [CHN], [CHN-01] only
5 - 13
DESCRIPTION
SY-12-K
72/98/005/X98/X98 except [CHN], [CHN-1]
MMZ1608Y 102BT
S.=Surface mount
