DV2
USER GUIDE
Dock & Play Vehicle Kit

Advertisement

Table of Contents
loading

Related Manuals for Sirius XM RAdio DV2

Summary of Contents for Sirius XM RAdio DV2

  • Page 1 USER GUIDE Dock & Play Vehicle Kit...

  • Page 2: Table Of Contents

    Table of Contents Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Introduction .

  • Page 3: Compatibility

    Compatibility This Vehicle Kit is compatible with the following Dock & Play Radios: • XM XpressEZ • XM XpressR • XM XpressRC • XM XpressRCi • XM Onyx • SiriusXM Edge This Vehicle Kit is not compatible with the following Dock & Play Radios: • Mirge • Xpress • Sportscaster...

  • Page 4: Introduction

    Introduction Features Thank you for purchasing the SiriusXM Dock & Play PowerConnect Additional Vehicle Kit! Your new Additional Vehicle Kit has everything you need to use your compatible SiriusXM Dock & Play Radio in another vehicle . • Add Satellite Radio to an additional vehicle: No need for a second subscription .

  • Page 5: Safety And Care Information

    Introduction Safety and Care Information IMPORTANT! Self installation instructions and tips are provided for your convenience . It is your responsibility to determine if you have the knowledge, skills, and physical ability required to properly perform an installation . SiriusXM shall have no liability for damage or injury resulting from the installation or use of any SiriusXM or third party products .
  • Page 6 Introduction WARNING! • Opening the case may result in electric shock . • Make sure that you insert the PowerConnect Power Adapter’s plug all the way into the vehicle’s cigarette lighter or power adapter socket . • If you are using PowerConnect as your audio connection option, it is advisable not to insert a multi-outlet adapter into the same vehicle cigarette lighter or power adapter socket to simultaneously power other devices .

  • Page 7: What's In The Box

    Introduction What’s in the Box? PowerConnect™ Vehicle Dock Dash Mount Vent Mount and Extended Vent Clamps Aux In Cable Screws (4) Magnetic Mount PowerConnect Antenna Cable Alcohol Antenna Power Adapter Routing Adapter Preparation Pads TIP! For other accessories you can add to your Vehicle Kit – from a Remote Control for ease of use, to a Cassette Adapter for vehicles with a cassette player, to professional installation if you’d rather leave your in-vehicle setup to the experts –...

  • Page 8: Powerconnect Vehicle Dock

    Introduction PowerConnect Vehicle Dock Color-Coded Connections The color-coded PowerConnect Vehicle Dock makes it simple to connect . Just match the colors on the cable ends to the colors on the dock to see what goes where . Rear View AUDIO ANT (Silver) PWR (Red) AUDIO (Green)
  • Page 9 Introduction Wire Guide The PowerConnect Vehicle Dock has a wire guide at the top rear to help organize the cables and wires connected to the dock . If you need to bring a cable or wire from one side of the dock to the other, utilize the wire guide by looping the cable though the wire guide as shown .

  • Page 10: Vehicle Installation

    Vehicle Installation WARNING! DO NOT attempt to install this Vehicle Kit while driving . Park your vehicle in a safe location before beginning installation . Step 1: Choose a Location for Your Radio When installing the PowerConnect Vehicle Dock in your vehicle, choose a location where it will not block your vision, interfere with the controls, or obstruct the air bag .
  • Page 11 Vehicle Installation Option 1 - Dash Mount Option 3 - Dash Mount Option 2 - Dash Mount...
  • Page 12 Vehicle Installation Option 4 - Vent Mount Option 5 - Vent Mount...

  • Page 13: Step 2: Install The Dash Or Vent Mount

    Vehicle Installation Step 2: Install the Dash or Vent Mount Follow the instructions on the next several pages for the mounting method you have selected . NOTE! The PowerConnect Vehicle Dock included with the this Vehicle Kit is compatible with the T-slot style Dash and Vent Mounts . If you have an existing Dash Mount or Vent Mount in your vehicle, you can continue to use it with this dock, and skip this step .
  • Page 14 Vehicle Installation correct, tighten the knob . Knob Adhesive Foot Dock Mounting Plate 4. Attach the Dash Mount to the PowerConnect Vehicle Dock using the 4 provided screws . 5. Before you attach the Dash Mount to the dash, skip ahead and finish the remainder of the vehicle installation so that the cables are attached to the dock .
  • Page 15 Vehicle Installation Installing the Vent Mount: IMPORTANT! To make the cable connections easier, wait until after you have connected all the cables to the dock before you attach the Vent Mount to a vent . Extended Vent Clamps 1. Locate a vent with horizontal louvers sturdy enough to hold your PowerConnect Vehicle Dock and Radio .
  • Page 16 Vehicle Installation 3. Attach the Vent Mount to the PowerConnect Vehicle Dock using the 4 provided screws . 4. Before you attach the Vent Mount to the vent, skip ahead and finish the remainder of the vehicle installation so that the cables are attached to the dock .

  • Page 17: Step 3: Mount The Magnetic Mount Antenna

    Vehicle Installation Step 3: Mount the Magnetic Mount Antenna Mount the Magnetic Mount Antenna on the outside of your vehicle, on a horizontal surface that will always face the sky . The antenna contains a strong magnet which will stick to any metal part of your vehicle, but will not damage the vehicle .
  • Page 18 Vehicle Installation SUV: We recommend mounting the antenna at the rear of the roof as shown . Convertible: We recommend mounting the antenna at the leading edge of the trunk as shown . Pickup Truck: We recommend mounting the antenna just above the front windshield as shown .
  • Page 19 Vehicle Installation 3. If you are installing the antenna at the roof edge, or hood edge, install the Cable Routing Adapter to direct the antenna cable downward . Without Cable With Cable Routing Adapter Routing Adapter Installed Installed Cable Routing Adapter orientation Place the antenna Slide the Cable Routing...
  • Page 20 Vehicle Installation 4. Place the antenna in the location you selected . Follow the Tips and Cautions shown on the next several pages . TIP! Mount the antenna on the roof (for most vehicles) or trunk (for convertibles) where it has a clear view of the sky in all directions .
  • Page 21 Vehicle Installation CAUTION! Don’t mount the antenna inside the vehicle, for example, on the dashboard . CAUTION! Don’t mount the antenna on any of the vehicle’s front, back or side pillars . CAUTION! Don’t mount the antenna close to a roof rack . Adjust the rack so it’s further away from the antenna or move the antenna closer to the center of the roof .
  • Page 22 Vehicle Installation CAUTION! Don’t mount the antenna close to another antenna . Mount it at least 3 inches away .

  • Page 23: Step 4: Route The Magnetic Mount Antenna Cable

    Vehicle Installation Step 4: Route the Magnetic Mount Antenna Cable Before you begin routing the antenna cable, read these general instructions for how to route and hide the antenna cable . Then route your antenna cable according to the instructions which follow for your specific type of vehicle . Use a blunt plastic putty knife, a credit card, a plastic knife, or a similar blunt tool to lift the rubber window moulding...
  • Page 24 Vehicle Installation Route cable out from under rear windshield moulding and tuck into weatherstripping around trunk opening Avoid sharp bends by running cable through Pull weatherstripping weatherstripping for several inches from trunk opening Tuck cable into weatherstripping. Route cable through weather- stripping several inches to avoid sharp bends Pull cable out of weatherstripping...
  • Page 25 Vehicle Installation Bring cable out of weatherstripping and into trunk Route cable along trunk wall and into cabin through gap or conduit, along existing wiring harness Route cable along trunk wall and into cabin...
  • Page 26 Vehicle Installation Use a blunt plastic putty knife or similar blunt tool to lift edge of interior trim and tuck cable Route cable under under trim. Continue trim or upholstery towards front of vehicle Continue routing cable under trim or carpet towards front of vehicle Route cable from trunk under interior trim, into...
  • Page 27 Vehicle Installation Continue routing cable under carpet or console to radio location Coil excess cable under Pull carpet carpet or mat or mat back Bring cable out from trim Bring cable out from trim and route under carpet to dashboard or console TIP! Always be careful to include enough slack in your cable to accommodate open doors or trunk lids .
  • Page 28 Vehicle Installation Sedan/Coupe With the Antenna Placed at the Rear of the Roof: 1. Feed the antenna cable from the antenna underneath the rubber molding around the rear window . Use a blunt plastic putty knife or similar blunt tool to lift the rubber molding around the rear window and tuck the antenna cable underneath the molding .
  • Page 29 Vehicle Installation locations are marked with “SRS” logos . Be careful not to crimp or cut the cable . 5. Bring the cable out from the trim near the front of the cabin and route it under the carpet toward the dashboard or console . Coil any excess cable in a hidden location, such as under the carpet, keeping it away from any vehicle pedals or controls .
  • Page 30 Vehicle Installation Sedan/Coupe With the Antenna Placed at the Front of the Roof: 1. Feed the antenna cable from the antenna underneath the rubber molding around the windshield . Use a blunt plastic putty knife or similar blunt tool to lift the rubber molding around the windshield and tuck the antenna cable underneath the molding .
  • Page 31 Vehicle Installation SUV: 1. Feed the antenna cable underneath the rubber weather stripping of the rear tailgate window/door and route the cable along the rear hatch . Lift the weather stripping from the opening and tuck the cable inside it, then replace the weather stripping . Pull the cable out from weather stripping and route it into the cabin under the interior trim .
  • Page 32 Vehicle Installation Convertible: 1. Bring the antenna cable from the antenna into the trunk at the front edge of the trunk lid . Keep any bends in the cable loose . Tape or tie the cable along the inside of the trunk lid to the trunk lid hinge strut . 2.
  • Page 33 Vehicle Installation Pickup Truck: 1. Use a blunt plastic putty knife or similar blunt tool to lift the rubber molding around the windshield and tuck the antenna cable underneath it . 2. Continue tucking the cable underneath the windshield molding around the windshield to the lowest corner .

  • Page 34: Step 5: Connect The Magnetic Mount Antenna And Powerconnect

    Vehicle Installation Step 5: Connect the Magnetic Mount Antenna and PowerConnect Power Adapter 1. Plug the Magnetic Mount Antenna into the silver ANT connector on the PowerConnect Vehicle Dock . AUDIO 2. Insert the PowerConnect Power Adapter into your vehicle’s cigarette lighter or power adapter socket .

  • Page 35: Step 6: Connect The Audio

    Vehicle Installation Step 6: Connect the Audio To play audio through your vehicle’s stereo or FM radio, decide on one of the following audio connection options: • Option 1: Best: Use the provided Aux In Cable if your vehicle’s stereo system has an auxiliary input connection or jack . Refer to your vehicle’s owners manual to find the location of the auxiliary input jack, or consult the vehicle dealer .
  • Page 36 Vehicle Installation Option 1: Aux In Cable Installation Instructions 1. Plug one end of the Aux In Cable into the green AUDIO connector on the dock . AUDIO 2. Plug the other end into the auxiliary input jack connection of your vehicle’s stereo system . 3.
  • Page 37 Vehicle Installation indication of signal strength . The Satellite and Terrestrial bars show the strength of the signal being received . If the signal reception is good, exit the Antenna Aiming or Signal Indicator screen and continue with step 8 . 8.
  • Page 38 Vehicle Installation Option 2: Cassette Adapter Installation Instructions 1. Plug the Cassette Adapter into the green AUDIO connector on the dock . AUDIO 2. Insert the Cassette Adapter into the vehicle’s cassette deck . You may need to turn on your vehicle’s stereo system in order to do so .
  • Page 39 Vehicle Installation Aiming or Signal Indicator screen of your Radio, to see a visual indication of signal strength . The Satellite and Terrestrial bars show the strength of the signal being received . If the signal reception is good, exit the Antenna Aiming or Signal Indicator screen and continue with step 8 .
  • Page 40 Vehicle Installation Option 3: PowerConnect Installation Instructions 1. If you are using the vent mounting method, attach the Vent Mount to the vent . 2. Insert your Radio into the dock . NOTE: Your Radio may be a different model than the Radio shown here .
  • Page 41 Vehicle Installation radio to tune through each FM channel one-by-one (88 . 1 followed by 88 .3 etc .) to locate channels that aren’t being used by a local FM radio station . Write down each FM channel that has only static or silence on it, until you reach 107 .9 .
  • Page 42 Vehicle Installation instructions . menu 99. 3 jump MATCH FM CHANNELS 9. You should hear audio through your vehicle’s FM radio . If you are satisfied with the sound quality, the PowerConnect installation is complete . 10. Go back to “Step 2: Install the Dash or Vent Mount” on page 13 and finish installing the Dash or Vent Mount .

  • Page 43: Troubleshooting

    Troubleshooting The Vehicle Kit has been designed and built to be trouble-free, but if you experience a problem, try this: • Check that all connections are firm and secure . • Make sure the vehicle power socket is clean and free of corrosion . • Make sure you have connected the Vehicle Dock as described in this User Guide .
  • Page 44 Troubleshooting If you see this on the screen: Try this: Channel Off Air • The channel you’ve selected is not currently broadcasting . Tune to another channel . Loading or • Your Radio is acquiring audio or program Acquiring Signal information . This message usually goes away in a few seconds .
  • Page 45 Troubleshooting If this happens: Try this: No audio when using the Aux In • Check all cables between your Radio and Cable or Cassette Adapter your vehicle’s stereo system for a firm and secure connection . • Ensure you have selected the proper input source on your vehicle’s stereo system .
  • Page 46 Troubleshooting If this happens: Try this: No audio when using • Check that your Radio and your vehicle’s FM PowerConnect or FMDA radio are tuned to the same FM channel . • Check that the FM transmitter in your Radio is On . Refer to your Radio’s User Guide (go to www .siriusxm .com/guides) for instructions .

  • Page 47: Product Specifications

    Product Specifications System Power Requirements: 9-16 V DC, 500 mA (max) Operating Temperature: -4°F to +140°F (-20°C to +60°C) Audio Output: 1 .0 V rms (max) PowerConnect Vehicle Dock Dimensions: 4 .0 in (width) x 2 .3 in (height) x 1 .2 in (depth) 102 mm (width) x 59 mm (height) x 31 mm (depth) Weight: 1 .6 oz (46 g) Audio Connector:...

  • Page 48: Patent And Environmental Information

    Patent and Environmental Information Patent Information It is prohibited to, and you agree that you will not, copy, decompile, disassemble, reverse engineer, hack, manipulate, or otherwise access and/or make available any technology incorporated in this product . Furthermore, the AMBE™ voice compression software included in this product is protected by intellectual property rights including patent rights, copyrights, and trade secrets of Digital Voice Systems, Inc .

  • Page 49: Fcc Statement

    • Consult the dealer or an experienced radio/TV technician for help . WARNING! The FCC and FAA have not certified Satellite Radio Receiver use in any aircraft (neither portable nor permanent installation) . Therefore, Sirius XM Radio Inc . cannot support this type of application or installation .

  • Page 50: Copyrights And Trademarks

    Copyrights and Trademarks ©2012 Sirius XM Radio Inc . “Sirius”, “XM” and all related marks and logos are trademarks of Sirius XM Radio Inc . “BBC” and “Radio One” are trademarks of the British Broadcasting Corporation and are used under license . BBC logo © BBC 1996 .
  • Page 52 Sirius XM Radio Inc . 1221 Avenue of the Americas siriusxm .com New York, NY 10020 1 .866 .635 .2349 © 2012 Sirius XM Radio Inc . XDPIV1UG 121008a...
