Sirius XM RAdio SiriusXM Quick Start Manual

SiriusXM Music For Business Internet Radio Quick Start Guide
Start Here

1. Subscribe to the SiriusXM Music for Business Internet Service

To listen to the SiriusXM Music for Business Internet Service, you will need to subscribe to the service. Call
1-866-345-SIRIUS (7474) to subscribe and obtain your SiriusXM username and password (credentials).

2. Connect the Radio

These instructions are for a wired connection to the Internet. Sirius XM strongly recommends a wired internet
connection for all business installations. An Ethernet cable is included.
Connect the Ethernet cable to the LAN connector of the Radio. Connect the other
A.
end to your local network.
Connect the Power Adapter to the DC 5V connector, and plug the Power Adapter to
B.
an AC outlet. The Radio will power on automatically (Figure 1).
If the Radio has successfully connected to the network, and has Internet
C.
connectivity, the Main Screen will be displayed (Figure 2).
If necessary, refer to the User Guide for more detailed network setup information.

3. Enter Your SiriusXM Credentials

From the Main Screen, turn the Scroll knob to the right to highlight Settings and press the knob to select.
A.
Turn the Scroll knob to highlight Credentials and press the knob.
B.
First enter the username that SiriusXM provided to you (Figure 3). The username is case sensitive. Turn
C.
the Scroll knob right and left to select a letter or number and press the knob to select the letter. If you
make a mistake, press the BACK button to erase the last entry.
Continue until you have finished entering the username. Then turn the Scroll knob
D.
until END is displayed and press the knob.
The Radio will display LOADING... while the username is being verified (Figure 4).
E.
Username updated will be briefly displayed if you entered the correct username. If
you have entered an incorrect username, Username does not exist will be displayed.
You will need to correct the username.
Next you will be prompted to enter your password. Enter your password in the same
F.
way as you entered your username. The password is also case sensitive. Then turn
the Scroll knob until END is displayed and press the knob.
After your password has been entered and successfully verified, you will be returned
G.
to the settings screen. Press BACK to return to the main display screen.

4. Selecting a Channel

The first time the Radio successfully connects to the SiriusXM Music for Business Internet Service, no channel will
have been selected to play.
If you are not at the main display screen, press and hold BACK until it is displayed.
A.
Highlight Category List and press the Scroll knob. The category list will be
B.
displayed (Figure 5).
You can select All Channels to browse through every available channel, or narrow the
C.
category list of channels by selecting Music, Talk & Entertainment, or Latin & World.
Turn the Scroll knob to highlight your selection and press the knob (Figure 6).
Use the BACK button to return to the previous screen as you search for a channel.
D.
Once you have located the channel to which you want to listen, highlight the channel
E.
and press the Scroll knob. When the Radio connects to the channel, the audio will
begin playing and the Now Playing screen will be displayed. For the initial audio
check, press the Speaker button to turn the speaker on.
Connecting to
LAN
|
12:00 AM
Figure 1
<Category List >
Settings
12:00 AM
Figure 2
Enter Username
~ CNL END <AaB
ABCDEF
12:00 AM
Figure 3
Loading...
|
12:00 AM
Figure 4
< All Channels >
Music
Talk and Enterta
12:00 AM
Figure 5
< Pop >
Rock
Hip-Hop/R&B
12:00 AM
Figure 6
