4-1 GENERAL specification

Test Resolution & Frequency
Test Image Size
Contrast and Brightness Controls

4-2 VIDEO INTERFACE

Analog Input Connector
Digital Input Connector
Video Input 1
Video Input 2
Video Input 3
Audio input 1
Audio input 2
Audio input 3
Default Input Connector
Video Cable Strain Relief
Video Cable Connector DB-15 Pin out
Video Signals
Video Impedance
Maximum PC Video Signal
Maximum Mac Video Signal
Sync Signals
DDC/CI
HDCP
Sync Compatibility
Video Compatibility
Video timing support
(CVBS / S-Video)
Video timing support
(HDMI / YPbPr)
Resolution Compatibility
ViewSonic Corporation
1920x1200 @ 60Hz
Full Size
Factory Default:
Contrast = 70%, Brightness = 100%
DB-15 (Analog), refer the appendix A
HDMI, 19pin Tape A
RCA jack (Red, Blue, Green) for YPbPr
RCA jack (Yellow) for CVBS
S-Video jack
3.5Mini Jack for PC Audio and (DVI-D adapter applied)
RCA jack (White / Red) for YPbPr
RCA jack (White / Red) for CVBS and S-Video, they will share the same RCA
jack
Defaults to the first detected input
D-Sub: 12Kg, 5min.
HDMI to DVI : 3Kg, 5min.
Composite(AV): 3Kg, 5min.
Compliant DDC / CI
1. Video RGB (Analog)
Separate,[ Composite, and Sync on Green (image quality no guarantee )]
2. TMDS (Digital)
(Need RCA to SCART for european market)
75 Ohms (Analog), 100 Ohms (Digital)
950 mV with no damage to monitor
1250 mV with no damage to monitor
TTL
Compliant with Revision 1.0
HDCP code inside and compatible
Separate Sync, [Composite Sync, SOG
(image quality no guarantee )]
Shall be compatible with all PC type computers, Macintosh computers, and
after market video cards
480i / 480p @ 60Hz
576i / 576p @ 50Hz
480i / 480p @ 60Hz
720p @ 50/60Hz
640x350 640x400
7
576i / 576p @ 50Hz
1080i / 1080p @ 50/60Hz
640x480
