General Specification; Video Interface - ViewSonic VX1935wm-3 Service Manual

2.

GENERAL specification

Test Resolution & Frequency
Test Image Size
Contrast and Brightness Controls
3.

VIDEO INTERFACE

Analog Input Connector
Digital Input Connector
Default Input Connector
Video Cable Strain Relief
Video Cable Connector DB-15 Pin out
Video Signals
Video Impedance
Maximum PC Video Signal
Maximum Mac Video Signal
Sync Signals
DDC 1/2B
Sync Compatibility
Video Compatibility
Resolution Compatibility
Exclusions
4. POWER SUPPLY
Internal Power Supply
Input Voltage Range
Input Frequency Range
Short Circuit Protection
Over Current Protection
Leakage Current
ViewSonic Corporation
1440x900 @ 60Hz
Full Size
Factory Default:
Contrast = 70%, Brightness = 100%
DB-15 (Analog),
DVI-D (Digital),
Defaults to the first detected input
Equal to twice the weight of the monitor for five minutes
Compliant DDC 1/2B
1. Video RGB (Analog)
Separate, Composite, and Sync on Green
2. TMDS (Digital)
75 Ohms (Analog), 100 Ohms (Digital)
950 mV with no damage to monitor
1250 mV with no damage to monitor
TTL
Compliant with Revision 1.3
Separate Sync, Composite Sync, SOG
Shall be compatible with all PC type computers, Macintosh
computers, and after market video cards
640 x 350*, 640 x 480, 720 x 400* (640 x 400*), 800 x 600, 832 x
624, 1024 x 768, 1152 x 864, 1152 x 870, 1280 x 720, 1280 x
960, 1280 x 1024 , 1400 x 1050 , 1440 x 900
* The image vertical size might not be full screen.
But the image vertical position should be at the center.
Not compatible with interlaced video
Part Number:ILPI-024
90 to 264 VAC (100~240VAC ±10%)
47 to 63 Hertz
Output can be shorted without damage
5.0 A typical at 14.0 VDC
3.5mA (Max) at 254VAC / 60Hz
Confidential - Do Not Copy
5
VX1935wm-3
