ViewSonic VX2835wm-1 Lcd Display page 94

EXPLODED PARTS LIST ( VX2835wm-1 )
ViewSonic Model Number: VS11531
Rev: 1a
Serial No. Prefix: QFG
Item ViewSonic P/N
1 B-00008444
C-00008464
N/A
M-00008126
2
M-00008125
N/A
N/A
N/A
3 C-00008469
4 C-00008468
5 N/A
6 N/A
7 C-00008470
8 M-00008124
9 C-00008467
10 C-00008466
11 N/A
12 N/A
13 C-00008465
14 N/A
15 N/A
16 N/A
17 N/A
18 PL-00008001
19 N/A
20 N/A
21 N/A
22 N/A
23 B-00008445
24 N/A
25 N/A
26 N/A
27 E-00008481
28 N/A
29 E-00008483
30 E-00008482
31 N/A
32 N/A
33 N/A
ViewSonic Corporation
Ref. P/N
70-V9350200G040 VX1935 KEY BOARD ASS'Y (LF)(Premier)
45-X2830100G000 VX2835 BEZEL SUB ASSY
40-04020019G000 VX2835 LED LENS
42-04170013G000 VX2835 Viewsonic logo for viewsonic,AL
42-04170012G000 VX2835 bird logo for viewsonic,AL
40-03010051G000 VX2835-BUTTON,ABS,BLACK
40-03010050G000 VX2835-BUTTON1,ABS,BLACK
40-01010097G000 VX2835-BEZEL,ABS-HB,BLACK
40-07010011G000 VX2835 HINGE COVER R,ABS HB,BLACK
40-07010010G000 VX2835 HINGE COVER L,ABS HB,BLACK
40-09010005G000 VX2835 cable clipper up,ABS-HB,pan 877c
40-09010006G000 VX2835 cable clipper down,ABS-HB,pan 877
40-11010002G000 VX2835 BASE COVER,ABS-HB,pan 877c
40-05010032G000 VX2835 ARM FRONT
40-05010033G000 VX2835 ARM COVER,ABS-HB,pan 877c
40-06010031G000 VX2835 BASE,ABS-HB,BLACK
41-03010073G000 VX2835 BASE BKT,SECC,t=2.0mm
41-07010027G000 VX2835 HINGE,SECC+AL
40-02010042G000 VX2835-BACK COVER,ABS-HB,BLACK
43-01041203-010 SCREW M4*12 W*6.8 T/2.5MM PAN BK TAP
43-01043001G040 SCREW,M4*30,PAN,PT,ZN
43-04040804G000 SCREW M4*8 FLAT BZ ME
43-04040804G010 SCREW M4*8 FLAT BZ TAP
42-02110002G000 HU171 Rubber Foot Black
41-04010030G000 VX2835 shielding,secc,t=0.8mm
43-12030502G000 SCREW M3*5 ROUND WASHER NI ME
43-12030801G010 SCREW M3x8 Round washer Zn Tap
70-Y2832500G000 VX2835 H/W PCB SUB ASSY
71-Y2831200G001 POWER MODULE 217W (PHIHONG)
43-01040605G400 SCREW M4*6,PAN,STAR Washer,CZ ,ME
41-03010072G000 VX2835 HINGE BKT,SECC,t=1.6mm
43-10040602G000 SCREW,M4x6L,CH,NI,ME
280MUW1-A00 LIQUID CRYSTAL DEVICE HSD280MUW1-A
43-12041002G010 SCREW M4*10 ROUND WASHER NI TAP
30-20033001G000 VX2835 SPEAKER 3.0W/8L LEFT
30-20033000G000 VX2835 SPEAKER 3.0W/8R Right
42-02110036G000 VX2835 SPEAKER RUBBER SPONGER
42-02110028G000 VX2835_SPEAKER_RUBBER
43-90000082G000 SCREW 4#-40*5*6.8 NI
Description
91
Confidential - Do Not Copy
Q'ty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
7
8
6
8
6
1
18
6
1
1
1
1
6
1
2
1
1
2
4
2
VX2835wm-1
