Exclusions
Audio / Video Action
RCA (white + red)
with CVBS
Audio
RCA (white + red)
input with YPbPr
3.5mm phone jack
Audio in HDMI
Video OVERSCAN
Component over scan: 5~8%
AV over scan: 5~8%
HDMI over scan: No over scan for PC input, 5~8% for video source.
PC: No over scan
4-3 POWER SUPPLY
Internal Power Supply
Input Voltage Range
Input Frequency Range
Short Circuit Protection
Over Current Protection
Leakage Current
Efficiency
Fuse
Power Dissipation
Max Input AC Current
Inrush Current
(Cold Start)
Power Supply Cold Start
Power Supply Transient Immunity
ViewSonic Corporation
720x480 800x600
1152x864 1152x870
1280x960 1280x1024
1440x900 1600x1200
The image vertical size might not be full screen.
But the image vertical position should be at the center.
Not compatible with interlaced video
Video input
CVBS S-Video
● ●
X X
X X
X X
Part Number: 71-Y2831200G001
AC90~264 (Worldwide)
47 to 64 Hertz
Output can be shorted without damage
3.3~4.5A typ. at 5 VDC
( Protect when short circuit )
3.5mA (Max) at 264VAC / 50Hz
80 % typical at 115VAC Full Load
Internal and not user replaceable
< 130 Watts (typ)
1.6A (max)
80 A Max./ 240VAC / 50Hz
(Cold Start at 25℃,Full Load)
Shall start and function properly when under full load, with all combinations of
input voltage, input frequency, and operating temperature
Shall be able to withstand an ANSI/IEEE C62.41-1980 6000V 200 ampere ring
wave transient test with no damage
8
832x624
1280x720
1360x768
1680x1050
YPbPr D-sub
X X
X
●
X
●
X X
Confidential - Do Not Copy
1024x768
1280x768
1400x1050
1920x1200
DVI-D via
HDMI
HDMI
X X
X X
X
●
X
●
VX2835wm-1
