4-7 TFT LCD PANEL
Panel Source Identify
The panel code "T" for HannStar panel should be shown on the position
1. Lower right side of ID label. (See Figure 2)
2. Lower right side of UPC label . (See Figure 3)
3. The F/W version sticker or silkscreen Main board.
Panel Characteristics:
st
1 Source Panel
Model number
Type
Active Size
Pixel Arrangement
Pixel Pitch
Glass Treatment
# of Backlights
Backlight Life
Luminance (5-point) –
Condition:
CT = User Color,
Contrast = Max,
Brightness = Max
Brightness Uniformity
Contrast Ratio
Color Depth
Viewing Angle (Horizontal)
TN type
Viewing Angle (Vertical)
TN type
Response Time
10%-90% @ Ta=25°C
Panel Defects
ViewSonic Corporation
HSD280MUW1-A
TN type with RSDS interface
27.5" wide; 593.28 (H) x 370.8 (V)
RGB Vertical Stripe
0.309 (H) x 0.309 (H) mm
Anti Glare (Hard coating 3H)
14 CCFL w/ Inverter / direct type
50000Hours (Min) at 6mA
500 cd/m2 (Typ after 30 minute warm up)
400 cd/m2 (Min after 30 minute warm up)
≧75% Entire Area (min)
800:1 (typ), 600:1(min)
16.7 million colors
@ CR>10
Typical: 160
Minimum: 150
@ CR>10
Typical: 160
Minimum: 150
Typical = 5ms (on/off) / 3ms (G to G)
Maxmum = 10 ms (on/off) / 7ms (G to G)
Please see Panel Quality Specifications.
19
