IMPORTANT SAFETY RECOMMENDATIONS FAILURE TO COMPLY WITH THE FOLLOWING SAFETY RECOMMENDATIONS MAY RESULT IN SERIOUS PERSONAL INJURY, DEATH AND/OR PROPERTY DAMAGE The installation of the Automatic Garage Door Opener The correct function of the safety reversing system should (Opener) must be carried out by a technically qualified or be checked on a monthly basis. Make sure that the door reverses easily when it makes licensed person. Attempting to install the Opener without suitable technical qualification may result in severe personal contact with an obstruction. Never use the Opener unless the door is in full view and injury, death and/or property damage. Only install the Opener on a well functioning, properly free from objects such as cars, children and/or adults. Never allow children to use the Opener. balanced and aligned garage door. An improperly balanced Never use the Opener when children/persons are under or or malfunctioning garage door could cause serious injury. Have a qualified person check and if required, make repairs near the path of the door. Children must be supervised at all times when near the door to the door before installing the Opener. As a general rule a garage door is deemed to be well balanced and aligned if it; and when the Opener is in use. Never attempt to disengage the Opener when there are A. requires an equivalent amount of applied force to ...
INSTALLATION INSTRUCTIONS The procedures outlined in this manual require a degree of technical and mechanical skill. The Opener should always be installed and adjusted by a technically qualified person. It is not recommended to be installed by a home handyman. Never install the Opener on a poorly adjusted or worn garage door. 1. Check for Correct Function of the Garage Door Before commencing installation of the Opener check that the garage door is functioning correctly. It must be well balanced and operate smoothly and freely and not bind or stick in the side tracks nor make contact with any supporting members. When released from any position it should not rise or fall more than 100mm. The effort required to open or close the door by hand should not exceed 150N (15kg). 2. Check Side Room Requirement The min and max mounting positions, as measured from the edge of the door curtain to the inner edge of its mounting bracket, are 40 and 50mm. (Fig.1) If the distance is less than 40mm or more than 50mm then door bracket must be moved so as to fall within the bounds of these 2 dimensions. 3. Select Installation Side Determine to which end of the door the Opener will be installed and select the dip switch according to the following: Left Hand Side Installation ‐ Dip 6 “ON” (Fig.7‐G) Right Hand Side Installation ‐ Dip 6 “OFF” (Fig.7‐G) ...
SETTINGS AND ADJUSTMENTS The following section outlines the selectable options and features which are available to the user 9. Engaging & Disengaging the Opener Important Note ‐ Always disengage the Opener with the door in the fully closed position. If disengaging from any position other than the door fully closed ensure that there are no persons or property near or directly under the path of the door. To Disengage To Engage Pull down on the red release cord (Fig.6) Pull down on the green release cord (Fig.6) 10. Transmitters – Learning & Deleting A. SIMPLE LEARNING Press desired Transmitter Button Function ...
SETTINGS AND ADJUSTMENTS 11. Door Height Enabling Function Dip 7 “OFF” – doors up to 2.5meters high Adjusts the open direction slow stopping point to cater for Dip 7 “ON” – doors over 2.5 meters high high doors 12. Door Travel Adjustment Important Note ‐ When adjusting limits always ensure that the Opener is disengaged from the door and not connected to the power supply Open Direction Close Direction Move the door by hand to the fully open position Move the door by hand to the fully closed position Remove light cover to expose Limit Cams (Fig. 7‐E & F) Rotate the “Close” Cam (Fig.7‐F) in the direction of the Loosen the 3 lock screws so that the Cams turn freely. limit switch until the switch is heard to “click” ...
SETTINGS AND ADJUSTMENTS Forced Learn Automatic Relearn May be initiated by long press of; An Automatic Re Learn will be initiated immediately Learn Button (Fig.6‐A or 7‐A) for 3 sec, or subsequent to either one of the following 3 occurrences; Button 4 of a Mass Learned transmitter – Run time deviation becoming excessive, or – Safety Reverse occurring on 3 consecutive occasions, or – Light will paused single blink once Opener has entered – Safety Stop occurring on 3 consecutive occasions. Forced Learn Mode Repeatedly cycle the opener During relearn LED (Fig.7‐I) will paused single blink then extinguish once relearn is complete – Light will extinguish once learning is complete M MODE Description Testing Close Direction Force Ensure that the garage door is resting firmly against the A less sensitive Safety Reverse system more suited for use suited for use on large, heavy or badly worn doors. ground. ...
SETTINGS AND ADJUSTMENTS 17. Door Service monitor Function Constantly monitors the spring balance of the garage door excessive. At this time the garage door should be serviced and warns the user when door is out of balance. Courtesy by a suitably qualified technician. lamp will triple blink every 15 sec once imbalance is To Enable Select Dip 4 to the “ON” position 18. LED Indicator Function Slow Blink – Opener has reached open limit position The LED (13‐I) provides Opener status information. Rapid Blink – Opener Learning new drive force values Indication Glow Solid – Opener has reached close limit position Intermittent Blink – Sleep Mode 19. Safety Beams ...
LED RUN A RUN B Courtesy Light Vacation Mode Run A Refer Sec.10 A1 Vacation Mode Refer Sec.10 A4 ………………………… ……………………………………………… Run B Refer Sec.10 A2 Battery Replacement Refer Sec.10 E ………………………… ……………………………… ...
