WARNING
Improper installation, adjustment,
alteration, service or maintenance can
cause injury or property damage.
Read the installation, operation and
maintenance instructions thoroughly
before installing or servicing this
equipment.
Failure to follow these instructions
could result in fire or explosion which
could cause property damage,
personal injury or death.
PROP 65 WARNING
Chemicals known to the state of
California to cause cancer, birth
defects, or other reproductive harm
are created by the combustion of
propane.
DANGER!
DO NOT use gas grill for indoor
cooking or heating. TOXIC fumes can
accumulate and cause asphyxiation.
NOT to be used in or on boats or
recreational vehicles.
WARNING
FOR YOUR SAFETY
For Outdoor Use Only
(outside any enclosure)
Tabletop Gas Grill
SAVE THESE INSTRUCTIONS FOR
FUTURE REFERENCE. IF YOU ARE
ASSEMBLING THIS UNIT FOR SOMEONE
ELSE, GIVE THIS MANUAL TO HIM OR HER
TO SAVE FOR FUTURE REFERENCE.
ITEM # 41242
Printed in China
Advertisement
Table of Contents
Related Manuals for BBQ 41242
Summary of Contents for BBQ 41242
- Page 1 ITEM # 41242 WARNING Improper installation, adjustment, Tabletop Gas Grill alteration, service or maintenance can cause injury or property damage. Read the installation, operation and maintenance instructions thoroughly before installing or servicing this equipment. Failure to follow these instructions could result in fire or explosion which could cause property damage, personal injury or death.
- Page 2 Grill Operation Quick Reference Before Grilling, Step 1 Keep your grill a safe distance away from your property.* Step 2 Always Perform a Leak Test on all connections and hoses.* Step 3 Keep children away from the grill. During Grilling, (To avoid tripping safety valves, please follow these instructions carefully!) Step 1 First open lid and turn gas valve on slowly.
-
Page 3: Table Of Contents
Table of Contents For Your Safety ....................2 Illustrated Part List ....................4 Assembly Instructions ..................6 Operating Your Grill Propane Tank Connection ........12 Checking for Leaks ..........13 Lighting Your Grill ..........13 Excess Flow Safety Valve Reset Procedure ……14 Care and Maintenance ........14 Award-Winning Barbecue Recipes ..............15 Troubleshooting ....................16 Warranty Program ....................17... - Page 4 To avoid burns, do not touch metal parts of the grill until they have completely cooled for at least 45 minutes or unless you are wearing protective gear such as pot holders, gloves, BBQ mittens, etc. Always open the grill lid carefully and slowly as heat and steam trapped within the grill could cause severe burns.
-
Page 5: Illustrated Part List
Illustrated parts list 1. Lid…………..…....1pc 2. Lid handle....…1pc 3. Body…..……….....1pc 4. Cooking grid………..…...1pc 5. Warming rack..……..…1pc 6. Side handle…....…2pcs 7. Side handle support..2pcs 8. Heat insulation board..2pcs 9. Burner..….……..……1pc 10. Heating plate....1 pc 11. Reflection plate.....1pc 12. Front support.....1pc 13. Back support....1pc 14. - Page 6 Hardware List (A screwdriver is also included for your convenience.) Bolt Clevis Pin M5 x10MM Ø6.5 X 45MM 8pcs 2pcs Hair Pin Bolt Ø1.3MM M6 x10MM 2pcs Bolt Gasket M5 x 45MM 4pcs 2pcs Lock Washer Ø6.0MM 15pcs 4pcs Flat Washer Screwdriver Ø6MM 15pcs...
-
Page 7: Assembly Instructions
Assembly Instructions For Best Results Remove all contents from packaging, and make sure all parts are present before attempting to assemble! Tighten all bolt connections by hand first, then when the grill is fully assembled, go back and tighten. It will take 5 10 minutes to assemble the grill. Step 1 Install the burner (9) and reflection plate (11) into the grill body (3) as... - Page 8 Step 3 Fix side handles (6), heat insulation board (8), side handle supports (7) and fastener (15) to the grill body as shown. Step 4 Install the lid handle (2) on lid (1) as shown. GAT1913-1 owner’s manual...
- Page 9 Step 5 Connect the top lid and body by insert the clevis pins (G) as shown. Step 6 Inserting the hair pin (H) through the hole in the end of each clevis pin as shown. GAT1913-1 owner’s manual...
- Page 10 Step 7 Put the heating plate (10) into the grill upon the burner as shown. Step 8 Put the warming rack (5) onto the heating plate as shown. GAT1913-1 owner’s manual...
- Page 11 Step 9 Place the cooking grid upon the heating plate as shown. Make certain the cooking grid is clipped by the fastener. Step 10 Install the grease cup (16) under the grill body as shown. GAT1913-1 owner’s manual...
- Page 12 Step 11 Turning the regulator valve (14) into the burner as shown. Step 12 Turn gas control dial to’’ OFF’’ position. Connect propane cylinder to cylinder regulator inlet fitting by turning as shown. Tighten all bolts after completely assembling. GAT1913-1 owner’s manual...
-
Page 13: Operating Your Grill Propane Tank Connection
Fully Assembled View Operating the Grill USE ONLY THE REGULATOR PROVIDED! If a replacement is necessary, please call our customer service center. The use of unauthorized parts can create an unsafe conditions and environment. Connecting gas cylinder: The propane-gas supply cylinder to be used must be constructed and marked in accordance with the Specifications for LP-gas Cylinders of the U.S. -
Page 14: Checking For Leaks
Checking for Leaks Make a 2-3 oz. of leak solution by mixing one part liquid dishwashing soap with three parts water. Make sure control knob is in the “OFF” position. Spray some solution on the tank valve up to the regulator connection. Inspect the solution at the connections, looking for bubbles. -
Page 15: Excess Flow Safety Valve Reset Procedure
Excess flow safety valve reset procedure • The new regulators are equipped with a safety device that restricts the gas flow in the event of a gas leak. However, unsafe practices of grill operation could activate the safety device without having a gas leak. •... -
Page 16: Award-Winning Barbecue Recipes
Award Winning Barbecue Recipes Hardcore Grilled Trout Never-fail Barbecue Sauce Ingredients: Ingredients: ¼ cup Lemon or lime juice ¼ cup Finely chopped onion 2 tablespoons Melted butter 2 tablespoons Butter or margarine 2 tablespoons Vegetable oil ¼ cup Brown sugar, firmly packed 2 tablespoons Chopped parsley 1 tablespoon... -
Page 17: Troubleshooting
Troubleshooting Problem Possible Cause Prevention/Cure Burner will not light using a match No gas flow Check if propane tank is empty. If empty, replace. If propane tank is not empty, refer to Excessive flow safety valve reset procedure. Obstruction of gas flow Clear burner tube. -
Page 18: Warranty Program
Warranty Program Proof of purchase is required to access this warranty program, which is in effect from the date of purchase. Inability to provide proof of purchase or after the warranty has expired, customers will be subject to parts, shipping and handling fees. Product Registration is required to receive full warranty coverage, which is in effect from the date of purchase.
