WARNING
Improper installation,
adjustment, alteration, service
or maintenance can cause
injury or property damage.
Read the installation, operation
and maintenance instructions
thoroughly before installing or
servicing this equipment.
DANGER
Failure to follow these
instructions could result in fire
or explosion that could cause
property damage, personal
injury or death.
DANGER
DO NOT use gas grill for indoor
cooking or heating. TOXIC
fumes can accumulate and
cause asphyxiation. DO NOT
use in or on boats or
recreational vehicles.
PROP 65 WARNING
Chemicals known to the state of
California to cause cancer, birth
defects or other reproductive
harm are created by the
combustion of propane.
WARNING
FOR YOUR SAFETY :
For Outdoor Use Only
(outside any enclosure).
KP1711
Owner's Manual
Portable Gas Grill
SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE. IF YOU ARE ASSEMBLING THIS UNIT
FOR SOMEONE ELSE, GIVE THIS MANUAL TO HIM OR
HER TO SAVE FOR FUTURE REFERENCE.
FOR CUSTOMER SERVICE OR
TECHNICAL HELP,PLEASE VISIT
WWW.BBQTEK.COM
SEND EMAIL TO
SERVICE@BBQTEK.COM
CALL 1-877-885-8227,
6 A.M. – 4:30 P.M.(PST),MONDAY-FRIDAY.
0
OR
Printed in China
Advertisement
Table of Contents
Related Manuals for BBQ Life@Home KP1711
Summary of Contents for BBQ Life@Home KP1711
- Page 1 Chemicals known to the state of California to cause cancer, birth defects or other reproductive harm are created by the combustion of propane. WARNING FOR YOUR SAFETY : For Outdoor Use Only (outside any enclosure). Printed in China KP1711 Owner’s Manual...
-
Page 2: Grill Operation
Always read and understand the WARNINGS and INSTRUCTIONS that are contained in this manual before attempting to use this gas barbecue grill, to prevent possible bodily injury or property damage. Always keep this manual in or near the grill, for convenient future reference. KP1711 Owner’s Manual... -
Page 3: Table Of Contents
Illustrated Parts List ..................5 Hardware List.....................5 Assembly Instructions..................6 Operating Your Grill...................9 LP Gas Supply Connection........ 9 Checking for Leaks..........10 Lighting Your Grill..........10 Excess flow safety valve reset procedure ..10 Care and Maintenance........12 Award-Winning Barbecue Recipes..............13 Troubleshooting....................14 Warranty Program.....................15 KP1711 Owner’s Manual... -
Page 4: For Your Safety
• Dented or rusted propane cylinders may be hazardous and should be checked by your propane gas supplier. • Never keep a filled container in a hot car or car trunk .Heat will cause the gas pressure to increase ,which may open the release valve and all gas flow to escape. KP1711 Owner’s Manual... - Page 5 Step 3. Ensure that the valve nozzle is pointing straight and completely inserted into the venturi tube. GENERAL INFORMATION 1. A propane gas cylinder is required for operation. 2. This gas grill is NOT intended for commercial use. KP1711 Owner’s Manual...
-
Page 6: Illustrated Parts List
6.Heat Insulation-SH..2pcs 7.Cooking Grid....1pc 8.Burner......1pc 9. Heating Plate…………..1 pc 10.Reflection Shield...1pc 11. Regulator....1pc Hardware List Bolt 6pcs 6pcs Burner Bolt Lock Washer 6pcs Heat Resistant Washer 6pcs 18pcs Washer Parts & Hardware shown above are not to scale. KP1711 Owner’s Manual... -
Page 7: Assembly Instructions
(6) and each side of the grill body (2). Screw a bolt (A) along with three heat resistant washer (F) into each pre- drilled hole and secure with a washer(C), a lock washer (E) and a nut (D). KP1711 Owner’s Manual... - Page 8 Screw a burner bolt (B) into the pre-drilled hole. Step 4 Insert the end of each wire leg (3) into each pre-drilled hole in grill body and into the holes on the heating plate(9) KP1711 Owner’s Manual...
- Page 9 Place the cooking grid (7) inside the grill body upon the heating plate. Place the lid on the grill body. Step 6 Draw the two wire legs upward to clip the lid and the grill body together in order to carry it. KP1711 Owner’s Manual...
-
Page 10: Operating Your Grill
4. Disconnect the propane cylinder from the regulator valve when the grill is not in use. 5. Do not obstruct the flow of combustion air and ventilation air to the grill. KP1711 Owner’s Manual... -
Page 11: Checking For Leaks
4. Clean the grill after each use. DO NOT use abrasive or flammable cleaners. This may damage parts of the grill and cause a fire. Observe flame height when lit: 2 in. Flame should be a blue/yellow color between 1 to 2 inches high. 1 in. KP1711 0 in. Owner’s Manual... -
Page 12: Excess Flow Safety Valve Reset Procedure
Observe flame height when lit: Flame should be a blue/yellow color between 1 to 2 inches high. 10. If the grill does not, turn the regulator valve to the “lock off” position” and disconnect the LP tank. Then, contact the customer service center for further assistance. KP1711 Owner’s Manual... -
Page 13: Care And Maintenance
Clean any clogged ports with a stiff wire (such as an opened paper clip) Inspect burner for any damage (cracks or holes). If damage is found, replace with new burner. Reinstall burner; check to insure that gas valve orifice is correctly positioned inside burner inlet (venturi). KP1711 Owner’s Manual... -
Page 14: Award-Winning Barbecue Recipes
Remove meat from marinade and grill over brushing them with marinade while they cook. very high heat to desired doneness. Heat leftover Cooking times will vary according to the vegetables marinade to a boil and pour over grilled steak to chosen. serve. KP1711 Owner’s Manual... -
Page 15: Troubleshooting
Burner and /or burner tubes are locked. Inside of lid is peeling – like paint The lid is stainless steel, not painted Baked on grease buildup has turned to peeling carbon and is flaking off. Clean thoroughl KP1711 Owner’s Manual... -
Page 16: Warranty Program
1-877-885-8227, 6:00 A.M. to 4:30 P.M. (PST), Monday through Friday. Manufactured by: Lucas Innovation Inc. Xiekeng District, QingXi Town, Dong Guan, Guang Dong, China Printed in China KP1711 Owner’s Manual...
