WARNING:
FOR YOUR SAFETY:
For Outdoor Use Only
(outside any enclosure)
GSC3219TN
Owner's Manual
DELUXE LP GAS GRILL
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
IF YOU ARE ASSEMBLING THIS UNIT FOR SOMEONE ELSE,
GIVE THIS MANUAL TO HIM OR HER TO SAVE FOR FUTURE
REFERENCE.
FOR CUSTOMER SERVICE, EMAIL TO
SERVICE@BBQTEK.COM OR CALL 1-877-885-8227
(TOLL-FREE), 07:00 A.M. – 16:00 P.M. (EST),
MONDAY-FRIDAY.
MODEL #GSC3219TN
Advertisement
Table of Contents
Related Manuals for BBQ GSC3219TN
Summary of Contents for BBQ GSC3219TN
- Page 1 Chemicals known to the state of California to cause cancer, FOR CUSTOMER SERVICE, EMAIL TO birth defects or other SERVICE@BBQTEK.COM OR CALL 1-877-885-8227 reproductive harm are created (TOLL-FREE), 07:00 A.M. – 16:00 P.M. (EST), by the combustion of natural MONDAY-FRIDAY.
-
Page 2: Grill Operation
Always read and understand the WARNINGS and INSTRUCTIONS that are contained in this manual before attempting to use this gas barbecue grill to prevent possible bodily injury or property damage. NOTE: This grill must be used with natural gas only Installer: Leave this manual with the consumer. Consumer: Retain this manual for future reference. GSC3219TN Owner’s Manual... -
Page 3: Table Of Contents
Assembly Instructions..................... 7 Operating Your Grill....................... 14 Natural Gas Connect…………………………………………………………………………...15 Checking for Leaks......................15 Lighting Your Grill......................16 Excess flow safety valve reset procedure ..............18 Care and Maintenance ....................19 Troubleshooting ......................20 Warranty Program ......................22 GSC3219TN Owner’s Manual... -
Page 4: For Your Safety
DANGER: Never use this outdoor grill inside any building, garage, shed or breezeway, or inside any boat, trailer or recreational vehicle to prevent a possible fire and to prevent the possibility of carbon monoxide poisoning or asphyxiation. GSC3219TN Owner’s Manual... -
Page 5: General Information
*** A clogged tube can lead to a fire beneath the grill. *** Step 3. Ensure that the valve nozzle is pointing straight and completely inserted into the venturi tube. General Information A natural gas hose is required for operation. This gas grill is NOT intended for commercial use. GSC3219TN Owner’s Manual... -
Page 6: Package Contents
1 PC Right side shelf 1 PC Grease cup 1 PC Grease cup support 1 PC Right side panel 1 PC Cart bottom 1 PC Right bottom side panel 1 PC left bottom side panel 1 PC GSC3219TN Owner’s Manual... -
Page 7: Hardware Contents
M4 spring washer 22 PCS M6 flat washer 1 PC 20 PCS M6 spring washer Screwdriver Hardware listed above is not scaled to exact size. (A screwdriver is required on assembly and is included for your convenience). GSC3219TN Owner’s Manual... -
Page 8: Assembly Instructions
Repeat the procedure with the right side panel (V) and the left side of cart bottom. Go back and tighten all the bolts using the screwdriver provided. M6×15 bolt 2 PCS M6 flat washer 2 PCS M6 spring washer 2 PCS GSC3219TN Owner’s Manual... - Page 9 (K) and the right end of front beam and back beam. e) Go back and tighten all bolts using the screwdriver provided. M4×15 bolt 8 PCS M4 spring washer 8 PCS M4 flat washer 8 PCS GSC3219TN Owner’s Manual...
- Page 10 . b) Push down the top pin of and insert it into left door the pre-drilled hole on the left end of front beam. Repeat the procedure for the right door (M). d) Close the two doors. GSC3219TN Owner’s Manual...
- Page 11 Tighten bolts by hand until secure. e) Repeat the procedure for the right top of cart assembly. Go back and tighten all bolts using the screwdriver provided. M6×15 bolt 4 PCS M6 flat washer 4 PCS M6 spring washer 4 PCS GSC3219TN Owner’s Manual...
- Page 12 (FF) into each pre-drilled hole. Tighten bolts by hand until secure. d) Go back to tighten all the bolts using screwdriver provided. M4×15 bolt 4 PCS M4 spring washer 4 PCS M4 flat washer 4 PCS GSC3219TN Owner’s Manual...
- Page 13 Place the side burner grate (Q) upon the side burner assembly. b) Place the heat plates (P) upon the burners. Place the cooking grids (O) upon the heat plates. Place the warming grate (N) on the sidewalls of fire box. GSC3219TN Owner’s Manual...
- Page 14 Make certain the natural gas hose is connected properly with gas inlet. Connect the gas inlet into the gas supply.Make certain the other end of the gas inlet is connected properly with gas supply. GSC3219TN Owner’s Manual...
-
Page 15: Operating Your Grill
Pipe sealing compound or pipe thread tape of the type resistant to the action of natural gas must be used on all male pipe threads. Apply compound or tape to at least the first three to four threads when making connections. Never store or use gasoline or other volatile substance in the vicinity of this grill. GSC3219TN Owner’s Manual... -
Page 16: Natural Gas Connect
6. Disconnect the natural gas hose from the valve and reconnect. Make sure the connection is secured. 7. Retest with solution. 8. If you continue to see bubbles, replace the quick release connector or/and natural gas hose. GSC3219TN Owner’s Manual... -
Page 17: Lighting Your Grill
If the burner does not light, repeat 2 or 3 more times. If ignition does NOT occur in 5 seconds turn the burner controls to OFF, wait 5 minutes, and repeat the lighting procedure. Adjust valve knob to the desired cooking temperature. GSC3219TN Owner’s Manual... - Page 18 5 minutes. Attempt to re-light. Clean your grill after each use, DO NOT use abrasive or flammable cleansers, as it will damage the parts of this product and may start a fire. Clean with warm soapy water. GSC3219TN Owner’s Manual...
-
Page 19: Excess Flow Safety Valve Reset Procedure
After the first front burner is lit, turn on the other control knob(s) to the HIGH position. If you have more than two burners, turn them on only ONE AT A TIME. When all front burners are lit, close the grill lid. Wait for 10-15 minutes; the temperature should reach 400 – 450°F. GSC3219TN Owner’s Manual... -
Page 20: Care And Maintenance
Inspect burner for damage (cracks or holes). If damage is found, replace with a new burner. Reinstall burner. Make certain the gas valve orifices are correctly positioned, pointing straight into burner inlet (venturi tube). Also, check position of spark electrode. GSC3219TN Owner’s Manual... -
Page 21: Troubleshooting
Spider webs or insect nest in Clean venturi. venturi. Food residue, grease or seasoning Clean burner. salt on burner. Poor alignment of valve to burner Assure burner venturi is properly venturi. engaged with valve. GSC3219TN Owner’s Manual... - Page 22 If flames are blue and noisy – close flap at the end of the venturi tubes in 1/8 in. increments until flames are correct. *Natural Gas Models must be open a minimum of 1/16 in. *Propane Models must be open a minimum of 1/8 in.. GSC3219TN Owner’s Manual...
-
Page 23: Warranty Program
If you have any questions related to the product or warranty, please visit our website at www.bbqtek.com or email us to service@bbqtek.com or call our customer service center at 1-877-885-8227, 07:00 A.M. to 16:00 P.M. (EST), Monday through Friday.
