WARNING:
Improper installation,
adjustment, alteration, service
or maintenance can cause
injury or property damage.
Read the installation,
operation and maintenance
instructions thoroughly
before installing or servicing
this equipment.
DANGER:
Failure to follow these
instructions could result in
fire or explosion that could
cause property damage,
personal injury or death.
DANGER:
DO NOT use gas grill for
indoor cooking or heating.
TOXIC fumes can accumulate
and cause asphyxiation. DO
NOT use in or on boats or
recreational vehicles.
PROP 65 WARNING:
Chemicals known to the state
of California to cause cancer,
birth defects or other
reproductive harm are created
by the combustion of
propane.
WARNING:
FOR YOUR SAFETY :
For Outdoor Use Only
(outside any enclosure)
SSS3416TB
Owner's Manual
Outdoor LP Gas Barbecue Grill
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
IF YOU ARE ASSEMBLING THIS UNIT FOR SOMEONE ELSE,
GIVE THIS MANUAL TO HIM OR HER TO SAVE FOR FUTURE
REFERENCE.
FOR CUSTOMER SERVICE, EMAIL TO
SERVICE@BBQTEK.COM OR
CALL 1-877-885-8225 (TOLL-FREE), 10:00 A.M. – 19:00 P.M.
(EST), MONDAY-FRIDAY.
0
MODEL# SSS3416TB
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for BBQ SSS3416TB
Summary of Contents for BBQ SSS3416TB
- Page 1 MODEL# SSS3416TB Outdoor LP Gas Barbecue Grill WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the installation, operation and maintenance instructions thoroughly before installing or servicing this equipment. DANGER: Failure to follow these...
-
Page 2: Grill Operation
NOTE: This grill must be used with propane gas only (propane gas cylinder not included). Installer: Leave this manual with the consumer. Consumer: Retain this manual for future reference. SSS3416TB Owner’s Manual... -
Page 3: Table Of Contents
Operating Your Grill....................... 14 Connecting Gas Cylinder ....................15 Checking for Leaks......................15 Lighting Your Grill......................16 Excess flow safety valve reset procedure ..............18 Care and Maintenance ....................19 Troubleshooting ......................20 Warranty Program ......................22 SSS3416TB Owner’s Manual... -
Page 4: For Your Safety
Move gas hoses as far away as possible from hot surfaces and dripping hot grease. Never keep a filled gas container in a hot car or car trunk. Heat will cause the gas pressure to increase, which could open the relief valve and allow gas to escape. SSS3416TB Owner’s Manual... -
Page 5: General Information
*** A clogged tube can lead to a fire beneath the grill. *** Step 3. Ensure that the valve nozzle is pointing straight and completely inserted into the venturi tube. General Information A propane gas cylinder is required for operation. This gas grill is NOT intended for commercial use. SSS3416TB Owner’s Manual... -
Page 6: Package Contents
1 PC Cup Support Left Door Store Basket Left Warming Rack 1 PC Front Beam 1 PC Maget Panel Right Warming Rack 1 PC Back Panel 1 PC Bracket 1 PC Cooking Grate 1 PC Bracket 2 PCS SSS3416TB Owner’s Manual... -
Page 7: Hardware Contents
M6 X 15 Bolt 18 PCS Spring Washer 10 PCS Flat Washer 10 PCS Screwdriver 1 PC Hardware listed above is not scaled to exact size. (A screwdriver is required on assembly and is included for your convenience). SSS3416TB Owner’s Manual... -
Page 8: Assembly Instructions
(O) with the four bolts extended from the right side cart panel and left side cart panel. Push down the back panel until it locks into place. d) Tighten all bolts using the screwdriver provided. SSS3416TB Owner’s Manual... - Page 9 Tighten bolts by hand until secure. d) Repeat the procedure for the left end of front beam. e) Go back and tighten all bolts using the screwdriver provided. M6X15 Bolt 4 PCS Spring Washer 4 PCS Flat Washer 4 PCS SSS3416TB Owner’s Manual...
- Page 10 Align the holes on the store basket (U) with the bolts extended from the bottom of the left door. g) Push down the store basket until it locks into place. h) Go back and tighten all bolts using the screwdriver provided. SSS3416TB Owner’s Manual...
- Page 11 Tighten bolts by hand until secure. e) Repeat the procedure for the left end assembly. Go back and tighten all bolts using the screwdriver provided. M6X15 Bolt 4 PCS Spring Washer 4 PCS Flat Washer 4 PCS SSS3416TB Owner’s Manual...
- Page 12 Insert one bolt (AA) into each pre-drilled holes. (See diagram to below.) Tighten bolts by hand until secure. e) Repeat the procedure for the assembly of left side shelf (B) and body assembly. Go back and tighten all bolts using the screwdriver provided. M6X15 Bolt 4 PCS SSS3416TB Owner’s Manual...
- Page 13 Close the top lid. Step 10 (Grease cup & support assembly) a) Hook the grease cup support (E) into the two holes on the grease pan. b) Place the grease cup (D) onto the grease cup support. SSS3416TB Owner’s Manual...
- Page 14 Place the gas tank on the tank holder and clip it using the tank clip. Connect the tank with regulator by screwing the regulator collar onto the tank valve. (See diagram to below) d) Conduct the leak test on page 15 to make certain all connections are connected securely. SSS3416TB Owner’s Manual...
-
Page 15: Operating Your Grill
DO NOT obstruct the flow of combustion air or ventilation air to the grill. Arrange the propane cylinder for vapor withdrawal and equipped with a listed overfill prevention device (OPD). SSS3416TB Owner’s Manual... -
Page 16: Connecting Gas Cylinder
If bubbles appear, you have a leak. Go to step 6. Disconnect the regulator from the tank and reconnect. Make sure the connection is tight and secured. Retest with solution. If you continue to see bubbles, replace the cylinder. SSS3416TB Owner’s Manual... -
Page 17: Lighting Your Grill
4. Clean the grill after each use. DO NOT use abrasive or flammable cleaners. This may damage parts of the grill and cause a fire. 2 in. 1 in. Observe flame height when lit: Flame should be a blue/yellow color between 0 in. 1 to 2 inches high. SSS3416TB Owner’s Manual... - Page 18 WARNING: Always monitor the grill closely when cooking and turn the flame level down to LOW or OFF if flare-ups intensify. SSS3416TB Owner’s Manual...
-
Page 19: Excess Flow Safety Valve Reset Procedure
When all front burners are lit, close the grill lid. Wait for 10-15 minutes; the temperature should reach 400 – 450°F. WARNING: The cylinder valve always has to be above the horizontal position, for the cylinder to have vapor withdrawl only. CORRECT WRONG WRONG WRONG SSS3416TB Owner’s Manual... -
Page 20: Care And Maintenance
Inspect burner for damage (cracks or holes). If damage is found, replace with a new burner. Reinstall burner. Make certain the gas valve orifices are correctly positioned, pointing straight into burner inlet (venturi tube). Also, check position of spark electrode. SSS3416TB Owner’s Manual... -
Page 21: Troubleshooting
Turn front of grill to face wind or Flame blow out. Increase flame height. Low on propane gas. Replace or refill propane tank. SSS3416TB Excess flow valve tripped. Refer to the Excessive flow safety Owner’s Manual valve reset procedure on page 18. - Page 22 If flames are blue and noisy – close flap at the end of the venturi tubes in 1/8 in. increments until flames are correct. *Propane Models must be open a minimum of 1/8 in. SSS3416TB Owner’s Manual...
-
Page 23: Warranty Program
If you have any questions related to the product or warranty, please visit our website at www.bbqtek.com or email us to service@bbqtek.com or call our customer service center at 1-877-885-8225, 10:00 A.M. to 19:00 P.M. (EST), Monday through Friday.
