WARNING:
Improper installation,
adjustment, alteration, service
or maintenance can cause
injury or property damage.
Read the installation,
operation and maintenance
instructions thoroughly
before installing or servicing
this equipment.
DANGER:
Failure to follow these
instructions could result in
fire or explosion that could
cause property damage,
personal injury or death.
DANGER:
DO NOT use gas grill for
indoor cooking or heating.
TOXIC fumes can accumulate
and cause asphyxiation. DO
NOT use in or on boats or
recreational vehicles.
PROP 65 WARNING:
Chemicals known to the state
of California to cause cancer,
birth defects or other
reproductive harm are created
by the combustion of
propane.
WARNING:
FOR YOUR SAFETY:
]
For Outdoor Use Only
(outside any enclosure)
SSS3416TC
Owner's Manual
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
IF YOU ARE ASSEMBLING THIS UNIT FOR SOMEONE ELSE,
GIVE THIS MANUAL TO HIM OR HER TO SAVE FOR FUTURE
REFERENCE.
FOR CUSTOMER SERVICE, EMAIL TO
SERVICE@BBQTEK.COM OR
CALL 1-877-885-8225 (TOLL-FREE), 07:00 A.M. – 16:00 P.M.
(EST), MONDAY-FRIDAY.
Service Center: 1-877-885-8225
0
MODEL
SSS3416TC
#

Advertisement

Table of Contents
loading

Summary of Contents for BBQ SSS3416TC

  • Page 1 MODEL SSS3416TC WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the installation, operation and maintenance instructions thoroughly before installing or servicing this equipment. DANGER: Failure to follow these instructions could result in fire or explosion that could cause property damage, personal injury or death.
  • Page 2: Grill Operation

    NOTE: This grill must be used with propane gas only (propane gas cylinder not included). Installer: Leave this manual with the consumer. Consumer: Retain this manual for future reference. SSS3416TC Owner’s Manual...
  • Page 3: Table Of Contents

    Operating Your Grill....................... 12 Connecting & disconnecting Gas Cylinder..............13 Checking for Leaks......................13 Lighting Your Grill......................14 Excess flow safety valve reset procedure ..............16 Care and Maintenance ....................17 Troubleshooting ......................18 Warranty Program ......................20 SSS3416TC Owner’s Manual...
  • Page 4: For Your Safety

    Never keep a filled gas container in a hot car or car trunk. Heat will cause the gas pressure to increase, which could open the relief valve and allow gas to escape. Safe Locations For Use Of This Outdoor Grill DANGER: Never use this outdoor grill inside any building, garage, shed or breezeway, or inside any boat, trailer or recreational SSS3416TC Owner’s Manual...
  • Page 5: General Information

    Step 3. Ensure that the valve nozzle is pointing straight and completely inserted into the venturi tube. General Information A propane gas cylinder is required for operation. This gas grill is NOT intended for commercial use. Don’t obstruct the ventilation opening of the cylinder enclosure. SSS3416TC Owner’s Manual...
  • Page 6: Package Contents

    2 PCS Storage basket support Cooking left grid 1 PC Latch magnet 1 PC 3 PCS 1 PC Heating plate Cylinder side support Cart left side panel 1 PC Tank baffle 1 PC Cart left door 1 PC SSS3416TC Owner’s Manual...
  • Page 7: Hardware Contents

    Hardware listed above is not scaled to exact size. (A screwdriver is required on assembly and is included for your convenience). SSS3416TC Owner’s Manual...
  • Page 8: Assembly Instructions

    Repeat the procedure with cart right side panel (S) and cart back panel (N). e) Go back and tighten all bolts using the screwdriver provided. M6 x 15 Bolt 2 PCS Spring washer 2 PCS Flat washer 2 PCS SSS3416TC Owner’s Manual...
  • Page 9 Insert one M6 x 15 bolt (AA), one spring washer (BB) and one flat washer (CC) into the each pre-drilled hole. Tighten all the bolts using the screwdriver provided. M6 x 15 Bolt 4 PCS Spring washer 4 PCS Flat washer 4 PCS SSS3416TC Owner’s Manual...
  • Page 10 (BB) and flat washer (CC) into pre-drilled holes, and tighten the bolts by hand. d) Go back and tighten all the bolts using the screwdriver provided. M6 x 15 Bolt 4 PCS Spring washer 4 PCS Flat washer 4 PCS SSS3416TC Owner’s Manual...
  • Page 11 Put the left cooking grid (I) and right cooking grid (H) upon the heating plates. Put the left warming rack (F) and right warming rack (G) on the side walls of firebox. d) Close the top lid. SSS3416TC Owner’s Manual...
  • Page 12 Place the gas tank on the gas holder, and then clip it using the tank clip. b) Connect the tank with regulator by screwing regulator collar onto the tank valve. Conduct the leaking test on page 13. SSS3416TC Owner’s Manual...
  • Page 13: Operating Your Grill

    DO NOT obstruct the flow of combustion air or ventilation air to the grill. The propane cylinder must be arranged for vapor withdrawal and equipped with a listed overfill prevention device (OPD). SSS3416TC Owner’s Manual...
  • Page 14: Connecting & Disconnecting Gas Cylinder

    If bubbles appear, you have a leak. Go to step 6. Disconnect the regulator from the tank and reconnect. Make sure the connection is tight and secured. Retest with solution. If you continue to see bubbles, replace the cylinder. SSS3416TC Owner’s Manual...
  • Page 15: Lighting Your Grill

    Confirm that the burner is properly lit and that the flame pattern is as desired (see fig. A, B and C below for the proper flame patterns). If the flame pattern is other than normal, consult the Troubleshooting on page 21 for corrective action. SSS3416TC Owner’s Manual...
  • Page 16: Excess Flow Safety Valve Reset Procedure

    A sudden shut off of the gas flow typically occurs if you open the LP tank valve rapidly, or if one or more of the burner ● control knobs is in an open position when opening the LP tank valve. SSS3416TC Owner’s Manual...
  • Page 17 When all front burners are lit, close the grill lid. Wait for 10-15 minutes; the temperature should reach 400 – 450°F. WARNING: The cylinder valve always has to be above the horizontal position, for the cylinder to have vapor withdrawl only. SSS3416TC Owner’s Manual...
  • Page 18: Care And Maintenance

    Inspect burner for damage (cracks or holes). If damage is found, replace with a new burner. Reinstall burner. Make certain the gas valve orifices are correctly positioned, pointing straight into burner inlet (venturi tube). Also, check position of spark electrode. SSS3416TC Owner’s Manual...
  • Page 19: Troubleshooting

    High or gusting winds. Turn front of grill to face wind or Increase flame height. Low on propane gas. Replace or refill propane tank. Excess flow valve tripped. Refer to the Excessive flow safety SSS3416TC valve reset procedure on page 16. Owner’s Manual...
  • Page 20 If flames are blue and noisy – close flap at the end of the venturi tubes in 1/8 in. increments until flames are correct. *Propane Models must be open a minimum of 1/8 in.. SSS3416TC Owner’s Manual...
  • Page 21: Warranty Program

    If you have any questions related to the product or warranty, please visit our website at www.bbqtek.com or email us to service@bbqtek.com or call our customer service center at 1-877-885-8225, 07:00 A.M. to 16:00 P.M. (EST), Monday through Friday. Manufactured by: Lucas BBQ Co., Ltd. Niuyang Industrial Zone, Liaobu Town, Dong Guan City, Guang Dong, China. Printed in China SSS3416TC Owner’s Manual...
