Comnet NW10E Quick Start Manual

Industrial outdoor high throughput 802.11a/n wireless ethernet

Advertisement

Quick Links

This manual serves the following
ComNet Model Numbers:
NW10
NW10E
QUICK START GUIDE
INDUSTRIAL OUTDOOR HIGH THROUGHPUT
802.11A/N WIRELESS ETHERNET
Thank you for purchasing NetWave
walk you through installation.
This guide applies to the following models:
NW10: Industrial Multipoint, FCC Version, User Configurable
NW10E: Industrial Multipoint, ETSI Version, User Configurable
An easy to read LED array displays unit operational status along with received signal
strength ensuring optimal installation and operation. See Figure 2 on Page 2 for LED
Indicator explanations.
See Figures 3 through 5 beginning on Page 3 for mounting instructions.
from ComNet. This quick start guide is designed to
®
INS_NW10_NW10E_QS_REV– 07/7/15 PAGE 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NW10E and is the answer not in the manual?

Questions and answers

Summary of Contents for Comnet NW10E

  • Page 1 QUICK START GUIDE INDUSTRIAL OUTDOOR HIGH THROUGHPUT 802.11A/N WIRELESS ETHERNET Thank you for purchasing NetWave from ComNet. This quick start guide is designed to ® This manual serves the following walk you through installation. ComNet Model Numbers: NW10 This guide applies to the following models:...
  • Page 2: Signal Strength

    QUICK START USER GUIDE NW10[E] FIGURE 1 – INDUSTRIAL HIGHTHROUGHPUT WIRELESS ETHERNET LINK PORT 1 - POE IN PORT 2 - POE OUT PORT 2 - POE OUT PORT 1 - POE IN FRONT BACK IMPORTANT: Only plug PoE power to Port 1. Connecting a PoE power source to the PSE Port (#2) will cause a major device malfunction and void the warranty.
  • Page 3 QUICK START USER GUIDE NW10[E] FIGURE 3 – INSTALLATION INSTRUCTIONS Step 1. Unpack the mounting hardware from the box. Determine if this will be a pole or wall mount application. The included Mounting kit is designed to support poles up to 2 in (5.8 cm) in diameter. If surface or wall mounting, the optional NWBKT hardware will be required.
  • Page 4 QUICK START USER GUIDE NW10[E] FIGURE 4 – POLE MOUNT INSTRUCTIONS Included Hardware Vertical Mount in -45º Position Vertical Mount in +45º Position TECH SUPPORT: 1.888.678.9427 INS_NW10_NW10E_QS_REV– 07/7/15 PAGE 4...
  • Page 5: Installation Requirements

    • Wireless mode – Set to AP or Client • Country code – Only required if setting up the NW10E and NWK7E/M (ETSI) models NOTE: It is the user’s responsibility to ensure that the correct country is chosen. ComNet accepts no liability for incorrectly set up equipment.
  • Page 6: Reset To Factory Default

    CONFIGURING MAC LOCK FOR POINT TO POINT LINKS MAC-Filter replaces MAC-Lock on the first generation Netwave hardware. MAC-Filter is only available on devices operating as an AP. By default, it is disabled. You can locate MAC-Filter tab by going to Networking -> WIFI -> Enable. To enable and lock to a client radio, Click on the drop down menu and select “Allow Listed Only”.
  • Page 7 TYPICAL POINT-TO-MULTIPOINT CONFIGURATION NOTE: NW10 and NW10E Multipoint nodes will need to have the Wireless Mode set to either AP or Client (default is Client). And the IP addresses will need to be all set to different addresses (default address is 192.168.10.101). Once this is done, all the clients will connect to the multipoint AP with all other settingst kept at default.
  • Page 8: Agency Compliance

    QUICK START USER GUIDE NW10[E] AGENCY COMPLIANCE Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: •...
  • Page 9 T: +44 (0)113 307 6400 | F: +44 (0)113 253 7462 | INFO-EUROPE@COMNET.NET © 2017 Communications Networks Corporation. All Rights Reserved. “ComNet,” the “ComNet Logo,” “NetWave,” and the “NetWave Logo” are registered trademarks of Communication Networks, LLC. INS_NW10_NW10E_QS_REV– 07/7/15 PAGE 9...
