Comnet NW10 Quick Start Manual

Industrial outdoor high throughput 802.11a/n wireless ethernet
Hide thumbs Also See for NW10:
1
2
3
4
5
6
7
8
9
Table of Contents

Advertisement

Quick Links

Download this manual
This manual serves the following
ComNet Model Numbers:
NW10
QUICK START GUIDE
INDUSTRIAL OUTDOOR HIGH THROUGHPUT
802.11A/N WIRELESS ETHERNET
Thank you for purchasing NetWave
walk you through installation.
This guide applies to the following models:
NW10: Industrial Multipoint, FCC Version, User Configurable
An easy to read LED array displays unit operational status along with received signal
strength ensuring optimal installation and operation. See Figure 2 on Page 2 for LED
Indicator explanations.
See Figures 3 through 5 beginning on Page 3 for mounting instructions.
from ComNet. This quick start guide is designed to
®
PAGE 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NW10 and is the answer not in the manual?

Questions and answers

Related Manuals for Comnet NW10

Summary of Contents for Comnet NW10

  • Page 1 QUICK START GUIDE INDUSTRIAL OUTDOOR HIGH THROUGHPUT 802.11A/N WIRELESS ETHERNET Thank you for purchasing NetWave from ComNet. This quick start guide is designed to ® This manual serves the following walk you through installation. ComNet Model Numbers: NW10 This guide applies to the following models:...

  • Page 2: Signal Strength

    QUICK START USER GUIDE NW10 FIGURE 1 – INDUSTRIAL HIGHTHROUGHPUT WIRELESS ETHERNET LINK PORT 1 - POE IN PORT 2 - POE OUT PORT 2 - POE OUT PORT 1 - POE IN FRONT BACK IMPORTANT: Only plug PoE power to Port 1.
  • Page 3 PoE Injector . PoE power input: Passive PoE (range 36 to 48 VDC). The NW10[E] can also be powered by a suitable IEEE 802.3af/at PSE device such as a PoE switch or injector.
  • Page 4 QUICK START USER GUIDE NW10 FIGURE 4 – POLE MOUNT INSTRUCTIONS Included Hardware Vertical Mount in -45º Position Vertical Mount in +45º Position TECH SUPPORT: 1.888.678.9427 PAGE 4...

  • Page 5: Installation Requirements

    8. Select the NETWORK -> WIFI tab and set: • Wireless mode – Set to AP or Client NOTE: It is the user’s responsibility to ensure that the correct country is chosen. ComNet accepts no liability for incorrectly set up equipment.

  • Page 6: Reset To Factory Default

    CONFIGURING MAC LOCK FOR POINT TO POINT LINKS MAC-Filter replaces MAC-Lock on the first generation Netwave hardware. MAC-Filter is only available on devices operating as an AP. By default, it is disabled. You can locate MAC-Filter tab by going to Networking -> WIFI -> Enable. To enable and lock to a client radio, Click on the drop down menu and select “Allow Listed Only”.
  • Page 7 PoE Camera NOTE: NW10 nodes will need to have the Wireless Mode set to either AP or Client (default is Client). And the IP addresses will need to be all set to different addresses (default address is 192.168.10.101). Once this is done, all the clients will connect to the multipoint AP with all other settingst kept at default.

  • Page 8: Agency Compliance

    QUICK START USER GUIDE NW10 AGENCY COMPLIANCE This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 9 T: +44 (0)113 307 6400 | F: +44 (0)113 253 7462 | INFO-EUROPE@COMNET.NET © 2017 Communications Networks Corporation. All Rights Reserved. “ComNet,” the “ComNet Logo,” “NetWave,” and the “NetWave Logo” are registered trademarks of Communication Networks, LLC. INS_NW10_NW10E_QS_REV– 07/7/15 PAGE 9...
