INSTRUCTION MANUAL
QUATTRO MICRO BATTERY CHARGER
INTRODUCTION
Thank you for your choice of the SKYRC Quattro Micro Battery Charger. This unit is
simple to use but its operation does require some knowledge on the part of the user.
Please read this entire operating manual completely and attentively before using this
product, as it covers a wide range of information on operating and safety.
SKYRC Quattro Micro Battery Charger employs the circuit that features four totally
independent but identical power outputs which are powered 4W each. It is designed for
charging single cell LiPo. Insert the battery lead to the right connector in each port, the
charger will charge 4 batteries at the same time. And the charging current can be
adjusted from 0.1-1A by dial, the charging capacity and cell voltage can be displayed in
each 4-digital LED Indicators.
Micro Reverse
MX
4-Digital LED
Indicator
Charging Status
LED Indicator
AC Input
Power Port
100-240V
Rotary Dial
for Setting
Charging Current
mCPX
Micro
SK-100079
DC Input
Power Jack
11-15V
Start/Stop
Button
