5.2.1

Ethernet port status

LANmonitor displays the current status of all of the device's Ethernet ports.
This includes monitoring of the state as configured by the admin (config state)
and the actual state (link state) of the port. Each port is displayed with two
colored symbols in LANmonitor:
The left icon shows the config state:
Gray: The port is deactivated in the configuration
Yellow: The port is activated in the configuration
The right-hand icon shows the link state:
Gray: No active network device is connected to the port
Green: A network device is connected to the port and active
Apart from the status, LANmonitor displays the VLAN ID for each port and the
detected data rate at active ports connected to active network devices.
