  • Page 1 Data Collection Terminal - RH768 - User’s Manual 400897G Version 1.0 Copyright 2011 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 2 Copyright 2011 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 3: Preface

    Registered trademarks of their respective companies and are hereby acknowledged. Unitech is a member of Oracle Embedded Software Licensing Program. Copyright 2012 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 4 Copyright 2012 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 5: Regulatory Compliance Statements

    This Class B Digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numerique de la classe B respecte les exigences du Reglement sur le material broilleur du Canada. Copyright 2012 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 6: European Conformity Statement

    USB Charging Cable or the Unitech RH768 Cradle. Initially charge the RH768 for at least 16 hours. Copyright 2012 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 7: Storage And Safety Notice

    140Fº (-20°C to 60°C); however, they may deplete more rapidly at the higher temperature ranges. It is recommended to store batteries within normal room temperature ranges. Copyright 2012 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 8: Warranty

    Use only the adapter supplied. Using the wrong adapter may damage the unit and will void the warranty. Copyright 2012 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 9: Table Of Contents

    Connecting the RH768 to a PC ................... 9 Turning the RH768 on for the First Time ................9 Using the Stylus ........................10 Copyright 2012 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 10 Toggle to Alpha Mode and CAPS ..................14 APPENDIX I System Specification ......................15 APPENDIX II Worldwide Support ........................ 17 viii Copyright 2012 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 11: Chapter 1 Getting Started

    RFID Middleware, supporting Microsoft B iztalk and Oracle Sensor Edge Server Support 860~960 MHz Support EPC G2 and ISO 18000-C Tag Copyright 2012 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 12: Package Contents

    Power Adapter Battery Pack Synchronization and Power Cable Please contact a regional Unitech service representative if anything is missing or appears damaged. Copyright 2012 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 13: Tour Of The New Rh768

    6 Scanner trigger button Press to activate the Bar Code Laser Scanner. Keypad interface for controlling the RH768. See the 7 Keypad Using the Hardware chapter for more information. Copyright 2012 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 14: Rear View

    Lithium-Ion 4050mAh Battery Pack. 15 Strap Hook Secures the strap to the RH768. 16 RFID Antenna Receives data from an RFID tag. Copyright 2012 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 15: Setting Up The Rh768

    Charge the RH768's main battery pack for at least 16 hours. Turn the RH768's Backup Battery Switch to the ON position before initial use. Copyright 2012 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 16 3. Align the Battery Contacts with the Battery Compartment Contacts as shown below: 4. Place the Battery Pack into the Battery Compartment and press the battery securely into place. Copyright 2012 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 17: Charging The Battery

    Plug the AC adapter cable into the power jack of the USB charging cable (2). Plug the AC adapter cord into an electrical outlet (3). Copyright 2012 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 18: Led Status

    Once the device is shut down, you should recharge the device within 48 hours. Otherwise you will lose all data including files stored in the RAM memory. Copyright 2012 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 19: Connecting The Rh768 To A Pc

    Turn on the device by pressing the Power Button on the front panel. The Unitech RH768 welcome screen appears followed by the calibration screen. Power Button Copyright 2012 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 20: Using The Stylus

    FUNC Key ESC Key Access the calibration screen at any time by simultaneously pressing the FUNC and ESC keys. Copyright 2012 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 21 Adjust the screen brightness by pressing the FUNC key to enable the soft keys and press the left arrow (decrease brightness) or right arrow (increase brightness) cursor buttons. FUNC Button Increase Brightness Decrease Brightness Copyright 2012 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 22 Copyright 2012 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 23: Using The Hardware

    When RH768 boots, the default condition is Numeric Mode on. When you toggle to Alpha Mode, the default condition is CAPS mode off. Please use the alpha Key to toggle to CAPS. Copyright 2012 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 24: Using Function Keys

    T, U, V, 8 w, x, y, z, 9 W, X, Y, Z, 9 , ; ! . / , ; ! . / Copyright 2012 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 25: Appendix I System Specification

    -10 °C ~ 50 °C Charging temperature 10 °C ~ 40 °C Storage temperature -20 °C ~ 60 °C Relative humidity 5% ~ 95% (non-condensing) Copyright 2012 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 26 USB communication and charging cable AC adaptor (with regional power cord) Accessories Vehicle Cradle Battery charger 4 slot Multi-Bay Ethernet Cradle Copyright 2012 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 27: Appendix Ii

    Unitech Asia Pacific & Middle East http://india.ute.com Greater China Division http://cn.ute.com Unitech Japan http://jp.ute.com Unitech America http://us.ute.com http://can.ute.com Unitech Latin America http://latin.ute.com Unitech Europe http://eu.ute.com Copyright 2012 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.
