Summary of Contents for RIKA ROCO
- Page 1 ROCO Operating Manual...
-
Page 2: Table Of Contents
Feeding in external combustion air .................................12 6. ASSEMBLY/DISMANTLING STONE AND OPTIONS Dismantling stone ....................................13 7. COMFORT OPTIONS RIKA room sensor/RIKA radio room sensor ............................15 RIKA GSM Control ....................................15 RIKA interface for various options .................................15 External room thermostat ..................................15 External connection cable bridge ................................15... -
Page 3: Preface
8. CLEANING AND MAINTENANCE Basic information ....................................16 Cleaning of the burn pot - daily ................................16 Empty the ash drawer .....................................16 Cleaning the door glass ..................................16 Cleaning flue pipes ....................................17 Cleaning the flame temperature sensor ..............................18 Cleaning the pellet container ..................................18 Bearings .........................................18 Checking door seal ....................................18 Cleaning of painted surfaces ..................................18... -
Page 4: Spare Part Overview Exploded Diagram
Spare part overview exploded diagram... -
Page 6: Spare Part Overview Article Numbers
Spare part overview article numbers Art.Nr.: Description Art.Nr.: Description Z34847 combustion chamber door black L02244 Hinge stove N103693 Culimeta flat packing black 8x2 LB00541 convection cover metallic L00475 glass holder LB00537 convection cover black N111799 Hexagonal screw M05x08 L02263 rear wall metallic Z34855 hinge plate L02245... -
Page 7: Dimensions
Dimensions Technical data Technical data ~43cm Heating power range [kW] 2,7 - 9 Room heating capacity (depending on house [m³] 50 - 240 insulation) Fuel consumption [kg/h] bis 2,2 Pellet container capacity [kg] Electric supply [V]/[Hz] 230/50 Average electrical input ~ 20 F-S* Fuse... -
Page 8: Important Information
First heating RIKA stoves should only be installed in rooms with normal humidity (dry The stove body, just as various steel parts, cast iron parts and the flue pipes areas according to VDE 0100 Part 200). The furnaces are not splash water are painted with a heat resistant paint. -
Page 9: Prior To Set Up
Prior to set up Stoves type 1 (BA 1): Floor bearing capacity Suitable for multiple occupancy. (Note the different country regulations.) Ensure that the substructure is capable of bearing the weight of the stove prior to set-up. These may only be operated with the combustion chamber door closed. Note The combustion chamber door is to be kept closed when the stove is not No modifications may be made to the firing installation. -
Page 10: Brief Information On Fuel Pellets
3. BRIEF INFORMATION ON FUEL PELLETS What are pellets? Note Please ask your pellet stove dealer for tested fuel and a list of monitored fuel Wood pellets are a standardised fuel. Every manufacturer must adhere to certain manufacturers. conditions in order to enable flawless, energy-efficient heating. Pellets are made Using poor quality or prohibited pellet fuel will have a negative effect on the from wooden waste, from sawmills and planning workshops, as well as from function of your pellet stove and can also lead to the warranty becoming null... -
Page 11: Technology And Safet Y Functions
4. TECHNOLOGY AND SAFET Y FUNCTIONS The technological advances in your new combi stove are the result of years of Component monitoring testing and practical experience. The practical advantages of your pellet stove are convincing: All the electrical components used are continuously monitored during operation. If a component is defective or can no longer be actuated correctly, then operation is stopped and a warning or error message is issued (see WARNING Operating comfort... -
Page 12: Installing The Stove
The stove can also be pushed on this cardboard or carpet. Feeding in external combustion air We recommend original flue pipes from RIKA for proper connection. only for devices which are able to run in room-air independent operation. Connection to the chimney Combustion air must be fed to the stove from outside via a sealed pipe for operation independent of the room air. -
Page 13: Assembly/Dismantling Stone And Options
6. ASSEMBLY/DISMANTLING STONE AND OPTIONS Remove the self-locking hex nut including the cover plate which is used to seal Note the pellet hopper. Only work on the unit when the mains plug has been disconnected and the stove has cooled down completely. Note During assembly / dismantling do not allow objects (screws etc.) to fall into the pellet container –... - Page 14 Now you can remove the two bottom hex nuts including washers. You can now lift off the bottom stone forward. Mount the removed parts in reverse order.
-
Page 15: Comfort Options
7. COMFORT OPTIONS We would point out that auxiliary units may only be connected to the RIKA External room thermostat interface connection and external connection socket by authorised specialists. Your stove has an interface on the rear wall to which you can connect a customary room thermostat. -
Page 16: Cleaning And Maintenance
8. CLEANING AND MAINTENANCE Basic information Cleaning of the burn pot - daily Make sure that the air vents are not blocked with ash or clinker. Remove the Note clinker using the supplied wire brush and vacuum the burn pot. Your stove must be switched off and cooled before any maintenance work is performed. -
Page 17: Cleaning Flue Pipes
Cleaning flue pipes Now clean the flues with the included wire brush. The flue pipes should be cleaned at least 2 x a year or after approx. 700 kg pellets. The flues are behind the combustion chamber. Loosen the 4 allen screws and slide the confection fins to the right. Remove the ash tray. -
Page 18: Cleaning The Flame Temperature Sensor
Cleaning the flame temperature sensor Bearings Remove the dust deposits from the sensor at regular intervals. Use a clean all built in bearings ( Pellet screw or turning Grid ) should be checked and cleaning cloth or newspaper. cleaned according to the condition or replaced min. once per Year. Checking door seal The condition of the seals at doors and glass should be checked at least 1 x per year. -
Page 19: Problems Possible Solutions
9. PROBLEMS POSSIBLE SOLUTIONS Problem 1 Problem 3 Fire burns with weak, orange flame. Pellets heap up in fire trough, window Flue gas discharge when wood is added and during heating phase. sooted up. Cause(s) Cause(s) Inspection openings leak Insufficient combustion air Chimney draught too low Poor chimney draught Flue pipe connection leaks... -
Page 20: Instructions For Commissioning Protocol
Note points, is a document. Please return 1 completed protocol for putting into service to RIKA Innovative Ofentechnik GmbH, Müllerviertel 20, 4563 Micheldorf, Austria. Warranty terms Difference between warranty (statutory) and guarantee (voluntary), terms of guarantee, determination of wearing parts, reference to pellet quality to be Electrical periphery used and the consequences of poor quality. - Page 21 Please contact your warranty partner for any warranty questions or claims. This is your dealer or installation company. No warranty claims can be accepted without proper putting into operation, proper operation according to the operating instructions and the supplements in this information sheet. Protocol for putting into operation for RIKA pellet and combi stoves Date:____________________...
-
Page 22: Guarantee
For the purpose of timely damage limitation, the warranty claim on the part of the claimant is to be enforced at the RIKA dealer in writing using the invoice and stating the purchase date, model name, serial number and reason for complaint. - Page 24 Technical and design changes, as well as typesetting and printing errors reserved © 2015 | RIKA Innovative Ofentechnik GmbH RIKA Innovative Ofentechnik GmbH 4563 Micheldorf / Austria, Müllerviertel 20 Telefon: +43 7582 686 - 41, Fax-DW: 43 E-Mail: verkauf@rika.at RIKA.AT...
