Icom IC-V80E Service Manual Addendum page 43

AF AMP
(IC5)
AF AMP CONTROLLER
(Q15)
MIC AMP
(IC13)
MIC GAIN
CONTROLLER
(Q81)
D/A CONVERTER
(IC10)
IF DEMODULATOR IC
(IC2)
LOOP FILTER SW
(Q58)
PLL IC
(IC1)
WIDE/NARROW SW
(Q83)
R5V REGULATOR
(Q21)
• MAIN UNIT
(BOTTOM VIEW)
CPU RESET IC
(IC8) (IC11)
2 - 2
RF AMP
(Q12)
1ST IF MIXER
(Q13)
TX POWER AMP
(Q1)
TX DRIVE AMP
(Q2)
VCO
VCO5V LINE REGULATOR
(Q11)
BACKLIGHT DRIVER
(Q25)
T5V LINE REGULATOR
(Q22)
SW5V LINE REGULATOR
(Q78)
CPU5V LINE REGULATOR
(IC12)
SW5V LINE REGULATOR
(Q56)
DTCS SW
(Q38)
EEPROM
(IC7)
